2.26 inch 16x2 1602 Character OLED Display Module Parallel SPI I2C Interface US2066(SSD1311) Driver ic LCD Character Display Mono White/Blue (Mono Blue)
- 2.26 inch diagonal,Passive Matrix 16x2 OLED Character Display
- Driver IC:US2066(SSD1311);Number of Characters: 16 Characters ( 5 × 8 ) × 2 Lines
- Interface:4-/8-bit 68XX/80XX Parallel, SPI, I2C; 33Pins
- Display Color: Monochrome(white/blue)
- Packing details:2.26" 16X2 Character OLED Display x1(pls reach out me if you have any Technic problem);
Preview of 2.26 inch 16x2 1602 Character OLED Display Module
2.26 inch monochrome character oled display module which is made with 16x2 characters. This mono 16x2 character oled screen sizes is 2.26 inch in diagonal. This 2.26 inch oled display is passive matrix micro OLED display. The controller IC is US2066, 2.26"oled screen supports 4-/8-bit 68XX/80XX Parallel, SPI, I2C interface, 3.3V power supply. The 2.26 oled is a COG structure OLED panel, oled could be emitting light by itself, no need for backlight, So the power required to run the OLED is low, and is why the display has such high contrast, extremely wide viewing angle and operating temperature. OLED 16x2 module can be operating at temperatures from -40℃ to +80℃, storage temperatures is from -40℃ to +85℃. The oled 16x2 character 2.26" is often used for smart watch, MP3, function cellphone, portable health device and many others application.
Features of 2.26 inch 16x2 1602 Character OLED Display Module:
2.26 inch monochrome character OLED.
Embedded Independent Driver Chip
Using SPI/I2C Interfaces.
emitting light by itself without backlight
Low power consumption
Parameter of 2.26 inch 16x2 1602 Character OLED Display Module:
Display Mode : Passive Matrix
Display Color : Monochrome(white/blue)
Drive Duty : 1/16 Duty
Display Size:2.26 inch
DriverlC:US2066(SSD1311)
Pin No:33P
Number of Characters: 16 Characters ( 5 × 8 ) × 2 Lines
Panel Size: 68.50 × 17.50 × 2.00 (mm)
Active Area: 56.22 × 11.52 (mm)
Character Pitch: 3.55 × 5.95 (mm)
Character Size: 2.97 × 5.57 (mm)
Pixel Pitch: 0.60 × 0.70 (mm)
Pixel Size: 0.57 × 0.67 (mm)
Interface:4-/8-bit 68XX/80XX Parallel, SPI, I2C
Operating Temperature:-40~850 °C
Storage Temperature：-40~90 °C
Part No:ZOJK226-1602ASWCG01
Weight: 4.98 (g)
Application of 2.26 inch 16x2 1602 Character OLED Display Module:
Smart phones
smart watch
portable health device
intelligent on-board camera
real-time display pictures
battery management equipment
IPC controller
MP3/MP4 player
mobile phone function
portable medical equipment, game, etc.
Packing Content:1x 2.26 inch 1602 monochrome character oled display
| Brand Name | AVITZ |
|---|---|
| Part Number | 00001 |
