PF10000673861
In stock
MINISFORUM Motherboard BD795M M-ATX Motherboard, AMD Ryzen 9 7945HX, 16C/32T, up to 5.4GHz, PCIe 4.0 x16 Slot, Dual NVMe M.2 Slots, 2X SATA3.0 HDD/SSD Slots, DDR5, 8K HDMI/DP, USB 3.2, RJ45 2.5G
$479.90
- POWERFUL PROCESSOR: Powered by the AMD Ryzen 9 7945HX processor with 16 cores and 32 threads, MINISFORUM motherboard BD795M delivers exceptional performance with clock speeds of up to 5.4 GHz. Paired with the integrated AMD Radeon 610M graphics, this motherboard delivers impressive computing and visual performance for gaming, content creation, and everyday multitasking, even without a discrete graphics card
- High-Speed DDR5 Memory and Dual M.2 SSD Slots: Experience fast performance with support for DDR5 memory up to 5200 MT/s and a total capacity of 96GB. Equipped with dual M.2 2280 NVMe SSD slots (PCIe 4.0x4), M-ATX Motherboard BD795M supports up to 4TB of blazing-fast storage, ensuring fast system boot-ups and smooth file transfers, making it the ideal choice for handling demanding applications and heavy workloads
- Advanced Cooling and Graphics Support: Designed for optimal performance, MINISFORUM BD795M motherboard supports a range of cooling solutions, including LGA 1700 air and water cooling options. It features a 100W CPU TDP that ensures stable operation under heavy loads. The metal-reinforced PCIe 4.0 x16 graphics slot provides secure support for high-end GPUs, delivering exceptional gaming and creative performance
- Versatile Connectivity for Seamless Integration: BD795M offers a multitude of I/O ports, including HDMI 2.1, DP1.4, USB 3.2 Gen1/USB 2.0, and 2.5 Gigabit LAN ports. These features provide fast data transfer speeds, high-quality display options, and reliable internet connectivity. The M.2 2230 E-Key connector also allows you to add a wireless card, reducing cable clutter and enabling high-speed wireless connectivity
- Flexible Storage Expansion: In addition to dual M.2 NVMe SSD slots, BD795M Motherboard also features dual SATA3.0 ports for connecting high-capacity hard drives or SSDs, providing flexible storage options for your system. It is recommended to use the BD795M motherboard to use a standard ATX power supply (>200W)
This product is fulfilled by seller
Processor: AMD Ryzen 9 7945HX, 16 cores and 32 threads, 5.4 GHz maximum turbo frequency, TDP 100W
Graphics card: AMD Radeon 610M
Memory: DDR5 5200 MT/s SO-DIMM х 2, up to 96GB
Storage:
2×M.2 2280 NVME SSD slot (PCIe 4.0x4, up to 4TB)
2×SATA3.0 interface"
Expansion interface: Wireless network card: M.2 2230 E-Key (PCIe Only)
Discrete graphics card: PCIe 4.0 x16"
Motherboard ports:
1 x 24-pin motherboard power port
1 x 8-pin +12V CPU power port
1 x 4-pin CPU fan pin
1 x 4-pin AIO Pump pin
3 x 4-pin SYS Fan Pins
1 x System Panel Pin
1 x Front Audio Pin (F_AUDIO)
1 x USB 3.2 Gen1 Pin
1 x USB 2.0 Pin
Video Output:
HDMI 2.1 FRL x 1 (Up to 8K@60Hz/4K@120Hz)
DP 1.4 x 1 (Up to 8K@60Hz/4K@120Hz) "
Audio Output:
HDMI х 1
Line Out х 1
Audio Input:
Line in х 1
Mic х 1
I/O Interface:
J45 2.5G Wired Network Port х 1
USB Type A(USB2.0) х 2
USB Type A(USB3.2 Gen1) х 2
HDMI 2.1 х 1
DP 1.4 х 1
Line in х 1
Line Out х 1
Mic *1
CLR COMS х 1
Power supply: ATX standard power supply (>200W)
Graphics card: AMD Radeon 610M
Memory: DDR5 5200 MT/s SO-DIMM х 2, up to 96GB
Storage:
2×M.2 2280 NVME SSD slot (PCIe 4.0x4, up to 4TB)
2×SATA3.0 interface"
Expansion interface: Wireless network card: M.2 2230 E-Key (PCIe Only)
Discrete graphics card: PCIe 4.0 x16"
Motherboard ports:
1 x 24-pin motherboard power port
1 x 8-pin +12V CPU power port
1 x 4-pin CPU fan pin
1 x 4-pin AIO Pump pin
3 x 4-pin SYS Fan Pins
1 x System Panel Pin
1 x Front Audio Pin (F_AUDIO)
1 x USB 3.2 Gen1 Pin
1 x USB 2.0 Pin
Video Output:
HDMI 2.1 FRL x 1 (Up to 8K@60Hz/4K@120Hz)
DP 1.4 x 1 (Up to 8K@60Hz/4K@120Hz) "
Audio Output:
HDMI х 1
Line Out х 1
Audio Input:
Line in х 1
Mic х 1
I/O Interface:
J45 2.5G Wired Network Port х 1
USB Type A(USB2.0) х 2
USB Type A(USB3.2 Gen1) х 2
HDMI 2.1 х 1
DP 1.4 х 1
Line in х 1
Line Out х 1
Mic *1
CLR COMS х 1
Power supply: ATX standard power supply (>200W)
| Brand Name | MINISFORUM |
|---|---|
| Part Number | 00001 |
| Compatible Processors | AMD Ryzen 9 7945HX |
| Memory Storage Capacity Unit | GB |
| Memory Storage Capacity | 0.000000 |
| Memory Clock Speed | 5200.000000 |
| Memory Clock Speed Unit | MHz |
| RAM Memory Maximum Size Unit | GB |
| RAM Memory Maximum Size | 96.000000 |
| Total PCIe Ports | 2 |
| Item Height Unit | Inches |
| Item Height base to top | 0.060000 |
| Item Length Unit | Inches |
| Item Length Longer Edge | 9.400000 |
| Item Width Unit | Inches |
| Item Width Shorter Edge | 8.600000 |
