Lever Nut 3 Wire Connector T-Type Universal Compact Push-in Terminal Block Wire T Tap Connectors Electrician Quick Splitter 18 PCS with Colored levers Kit for AWG 28-12 AWG.
- 【Universal Compatibility】: It is a universal 3-way connector for soft and hard wires, divided into concave and convex, butt terminal wire connector each wire connector is provided with 2 slots and 2 clasps on two sides, can be used in splicing.. The connector is extensive Used in home improvement wiring, hotel factory lighting connection, etc.
- 【Easy to detect】:In the transparent version, you can see the connection of the wires and confirm whether the wires are fully inserted into the holes. In addition, there is a test hole on the back of the connector. The test hole can be used to test whether it is energized or not. 18 PCS Yellow 3 Wire Connector Suitable for hard wire 0.08-4.0mm²/ AWG28-12, soft wire 0.08-2.5mm²/AWG28-14.
- 【Easy to detect】:In the transparent version, you can see the connection of the wires and confirm whether the wires are fully inserted into the holes. In addition, there is a test hole on the back of the connector. The test hole can be used to test whether it is energized or not. 18 PCS Yellow 3 Wire Connector Suitable for hard wire 0.08-4.0mm²/ AWG28-12, soft wire 0.08-2.5mm²/AWG28-14.
- 【Safe and durable】: Lever Nut Connector the shell is made of flame retardant material, high temperature resistance, reducing potential safety hazards. conductor is tinned with pure copper, strong conductivity, rust resistance and corrosion resistance. It has the fewest installer possibilities for error of any connector, like not tightening wire properly or with sufficient torque. It is very good at preventing thermal cycling release of wires connected together.
- 【Easy to Use】: Don't need any tools to connect wires, just using your hands. 1. Put the handle board to 90° 2. Strip the wire about 0.39inch(10mm) 3. Put down the handle 4. Wiring is complete.
Twining You don't have to entangle all the copper wires so that you may unravel the additional branches later and cut the brass wires so that the length of the brass wires is insufficient to connect.
Levers butt terminal wire connector Help with tracing wires and assorting wires in a clear and easy way. have Space Compact size is invaluable for all connection space requirements, offering you a clean and beautiful wire organization.
Practical Lever Wire Nuts Used for building and everyday household wiring: lights, sockets, switches, cars, loudspeakers, electrical boxes, fan controls, etc.
Rated Voltage: 250V/600V
Rated Current: 32A
Package includes: 18 PCS Lever Nut 3 Wire Connector T-Type
Connector Range of Uses :Wire Cross section 0.08~4.0mm²(hard wire ), 0.08~2.5mm²(soft wire)
How to use:
1, Open the housing of wire to 0.39inch (10mm);
2,Push the lever to 90° and insert the wire lead;
3，Press the lever to close the clamp;
4, Check the test hole whether it is connected correctly.
5，Electrical connections.
| Brand Name | N\\C |
|---|---|
| Part Number | 1 |
| Voltage Unit | Volts |
| Gauge Decimal Value | 12.000000 |
| Gauge String Value | 12 |
| Maximum Voltage Unit | Volts |
| Maximum Voltage | 600.000000 |
| Operating Voltage Unit | Volts |
| Operating Voltage | 500.000000 |
| Item Height Unit | Inches |
| Item Height base to top | 0.580000 |
| Item Length Unit | Inches |
| Item Length Longer Edge | 1.550000 |
| Item Width Unit | Inches |
| Item Width Shorter Edge | 1.030000 |
