Mcbazel OSSC SCART Component VGA to HDMI Open Source Scan Converter v1.6 for Retro Gaming Saturn SNES PS1 Console US Plug
$139.90
- Please ensure you know what is the product using for and how does it work . If there is any question please ask first before you place the order. DO NOT PURCHASE THIS UNLESS YOU UNDERSTAND WHAT IT DOES AND HOW IT WORKS
- Please refer to item descriptions for specification details. The remote control needs 2 AAA batteries (NOT incl.)
- It requires a suitable RGB high-quality SCART cable to work which is not included. The device will only work with RGB inputs. NOT work with converted/split cable connection.. JP21 adapter is required for JP21 RGB Cables.it cable connection.
- Works on all other retro consoles from Spectrum, Amiga, SNES, Gamecube (PAL), Saturn, Mega Drive to PlayStation and more. Will NOT work with Nintendo N64, Non-RGB modded Nintendo NES, or a NTSC Gamecube as these are both S-Video and NOT RGB. NOT compatible with sfcJR.
- Package Incl.: 1 x Open Source Scan Converter, 1 x Remote Control, 1 x Power Supply (US Plug), 1 x User Manual
- This is NOT an official product.
This product is fulfilled by seller
Descriptions:
Play your favorite retro games using this adapter by connecting your console to one of the OSSC's inputs. The adapter will then output the signal to HDMI for connection on a modern TV with no input lag. For v1.6, it converts not only VGA, SCART and Component to DVI/HDMI, but also analogue audio to digital DVI/HDMI now! The OSSC features multiple options and modes for tweaking the image until you are happy - A variety of templates to get the best image for each console are widely available online!
Input: 1 X SCART – Supports RGBs (clean csync, cvideo sync, luma sync), RGsB, Ypbpr 1 X Component video – Supports Ypbpr and RGsB signals
1 X D-SUB15 (VGA) – Supports RGBHV, RGBs, RGsB, Ypbpr
2 x 3.5mm analogue audio – Supports all analogue audio. Input 1 can be toggled between output (from AV1/SCART) or input
Composite video and S-Video are NOT supported and require an adapter/transcoder (NOT incl.)
Output:
1 X HDMI or DVI-D (w/ adapter) (digital only, incl.audio). Full-range 24-bit RGB output through DVI/HDMI
1 X Analogue audio 3.5mm (input/output toggle)
Supported input resolutions:
240p/288p/480i/576i 15khz
25Khz medium-res modes
480p/576p/720p/1080i 31khz
Supported output resolutions:
240p/288p -> 480p/576p or 720p line triple (compatible displays only)
240p/288p -> 1280×960, 1280×1152, 1080p, 1600×1200 line quadruple/quintuple (compatible displays only)
25Khz medium-res modes -> 480p
480i/576i -> 480p/576p or pass-through
480p -> pass-through or 960p line-double (compatible displays only)
all other 31khz resolutions passed through
Other Features:
Back lit LCD
SD Card socket for firmware updates
JTAG connector
IR receiver
Power requirements: DC 5V 1 Amp – 2.1 x 5.5mm positive tip
Play your favorite retro games using this adapter by connecting your console to one of the OSSC's inputs. The adapter will then output the signal to HDMI for connection on a modern TV with no input lag. For v1.6, it converts not only VGA, SCART and Component to DVI/HDMI, but also analogue audio to digital DVI/HDMI now! The OSSC features multiple options and modes for tweaking the image until you are happy - A variety of templates to get the best image for each console are widely available online!
Input: 1 X SCART – Supports RGBs (clean csync, cvideo sync, luma sync), RGsB, Ypbpr 1 X Component video – Supports Ypbpr and RGsB signals
1 X D-SUB15 (VGA) – Supports RGBHV, RGBs, RGsB, Ypbpr
2 x 3.5mm analogue audio – Supports all analogue audio. Input 1 can be toggled between output (from AV1/SCART) or input
Composite video and S-Video are NOT supported and require an adapter/transcoder (NOT incl.)
Output:
1 X HDMI or DVI-D (w/ adapter) (digital only, incl.audio). Full-range 24-bit RGB output through DVI/HDMI
1 X Analogue audio 3.5mm (input/output toggle)
Supported input resolutions:
240p/288p/480i/576i 15khz
25Khz medium-res modes
480p/576p/720p/1080i 31khz
Supported output resolutions:
240p/288p -> 480p/576p or 720p line triple (compatible displays only)
240p/288p -> 1280×960, 1280×1152, 1080p, 1600×1200 line quadruple/quintuple (compatible displays only)
25Khz medium-res modes -> 480p
480i/576i -> 480p/576p or pass-through
480p -> pass-through or 960p line-double (compatible displays only)
all other 31khz resolutions passed through
Other Features:
Back lit LCD
SD Card socket for firmware updates
JTAG connector
IR receiver
Power requirements: DC 5V 1 Amp – 2.1 x 5.5mm positive tip
| Brand Name | Mcbazel |
|---|---|
| Part Number | av-040038 |
| Current Rating Unit | Amps |
| Current Rating | 1.000000 |
| Input Voltage Unit | Volts |
| Input Voltage | 5.000000 |
| Nominal Power Unit | Watts |
| Nominal Power | 5.000000 |
