CONDOR 11KC2E Pressure Swtch, Dpst, 40 to 175 Psi, Stndrd
$24.99
- Factory Set Pressure Range: 140-175 PSI
- Pressure Switch Differential: 30 to 65 PSI
- Minimum Cut It Pressure: 40 PSI
- Maximum Cut Out Pressure: 160 PSI
- Max Switching Capacity: 26 Full Load Amps at 240 Volts
This product is fulfilled by seller
This pressure switch is designed for use with air compressors. It features an actuation-type diaphragm.
Item: Pressure Switch
Pressure Switch Application: Air Compressor
Manual Switch Action: Auto/Off
Pressure Switch Port Type: (4) Port, 1/4" FNPT
Pressure Switch Factory On/Off Setting: 140/175 psi
Pressure Switch Unloader: 1/4" Compression
Pressure Switch Differential: 30 to 65 psi
Pressure Switch Range: 40 to 175 psi
Pressure Switch Electrical Contact Form: DPST
Pressure Switch Action: Standard
NEMA Rating: 1
Series: MDR11
HP @ 1 Phase - 120V: 2
HP @ 1 Phase - 240V: 3
Temp. Range: -22 Degrees to 257 Degrees F
Standards: UL Listed, CSA Certified
Special Features: 4 kW/4 HP Switching Capacity, 11 Bar/160 psi Maximum Cut-Out Pressure
AC Contact Rating: 26A @ 240V
Item: Pressure Switch
Pressure Switch Application: Air Compressor
Manual Switch Action: Auto/Off
Pressure Switch Port Type: (4) Port, 1/4" FNPT
Pressure Switch Factory On/Off Setting: 140/175 psi
Pressure Switch Unloader: 1/4" Compression
Pressure Switch Differential: 30 to 65 psi
Pressure Switch Range: 40 to 175 psi
Pressure Switch Electrical Contact Form: DPST
Pressure Switch Action: Standard
NEMA Rating: 1
Series: MDR11
HP @ 1 Phase - 120V: 2
HP @ 1 Phase - 240V: 3
Temp. Range: -22 Degrees to 257 Degrees F
Standards: UL Listed, CSA Certified
Special Features: 4 kW/4 HP Switching Capacity, 11 Bar/160 psi Maximum Cut-Out Pressure
AC Contact Rating: 26A @ 240V
| Brand Name | CONDOR |
|---|---|
| Part Number | 11KC2E |
| Number of Positions | 4 |
| Wattage | 3.120000 |
| Current Rating Unit | Amps |
| Current Rating | 26.000000 |
| Upper Temperature Rating | 257.000000 |
| Lower Temperature Rating | -22.000000 |
| Operating Voltage Unit | Volts |
| Operating Voltage | 120.000000 |
| California Proposition 65 Warning Type | Chemical |
