PF10000649858
In stock
Pc Accessories - Connectors Pro 16P 10 Pack 1.27mm 0.05" Pitch Mini Dual Rows IDC FC Female Sockets Terminates to 0.635mm 0.025" Flat Ribbon Cable (FC-16P-10PK)
$19.95
- PRICE is for 10-PACK
- 2X8 16 PINS IDC SOCKET-RECEPTACLE 0.05" x 0.05" (1.27mm x 1.27mm) DUAL-ROW Sockets
- FEMALE CONNECTOR WITH POLARIZING CENTER BUMP, NO STRAIN RELIEF
- Specifications: Current Rating: 1AMP; Operation Temperature: -40°C to +105°C ; Contact Resistance: 20mΩ Max. at DC 100mA ; Insulation Resistance: 1000MΩ Min. at 500V DC
- MATES WITH 1.27 mm (0.05") PITCH HEADERS; TERMINATES TO 0.635mm (0.025") pitch FLAT RIBBON CABLE
This product is fulfilled by seller
PRICE is for 10-PACK. Dual-Row 127mm Socket, IDC, 16 Position, IDC Flat Ribbon crimp Connectors These connectors mate with any 1.27mm spaced dual-row pin headers. The insulation displacement (IDC) contacts on these connectors allow them to be quickly and easily crimped onto flat ribbon cable. NUMBER OF PINS:16P 2X8 IDC SOCKET-RECEPTACLE 1.27mm x 1.27mm DUAL ROW IDC FEMALE CONNECTOR FEMALE CONNECTOR WITH POLARIZING CENTER BUMP, NO STRAIN RELIEF SELECTIVE GOLD PLATING MATES WITH 1.27 mm PITCH HEADERS TERMINATES TO 0.635mm (0.025") FLAT RIBBON CABLE
| Brand Name | Connectors Pro |
|---|---|
| Part Number | 127-FC16P-10PK |
| Maximum Voltage Unit | Volts |
| Maximum Voltage | 500.000000 |
