Hydraulic Hand Pump, 10000Psi Manual Hydraulic Hand Pump, Hydraulic Hand Pump with Pressure Guage Suitable for Using Varieties of Hydraulic Tools
- ★【Durable Material】-- The item is made of steel, which is relatively strong and stable. It is also not easy to damage or rust under proper use and is very durable.
- ★【Large Reservoir Capacity】-- The large oil storage capacity of 900cc allows you to use it easily without frequent refueling.
- ★【User-friendly】--The manual hydraulic pump has a long ergonomic operating handle for a smoother, more comfortable grip during use. Its thickened insulation feature also provides non-slip hand protection for long-term use.
- ★【Strong Power】-- Under the condition of constant power, low pressure and large flow oil supply and high pressure and small flow oil supply can save time and improve efficiency. Its 10000Psi maximum output pressure also promotes its work efficiency.
- ★【Wide Use】-- This pump can be used together with other hydraulic tools, such as a hydraulic jack, hydraulic crimping machine, hydraulic punching machine, and hydraulic pipe bender.
Features
Integrated Structure: The product with an integrated structure can be directly used with jacks without an additional installation.
Easy to Use: The anti-skid long handle has a comfortable grip and labor-saving operation, which is convenient.
Details
Pressure Gauge: This product comes with a pressure gauge that allows you to know the working status of the product at any time for safer use.
High-pressure Oil Pipe: It adopts a high-pressure oil pipe (6.6 ft) and attaches a quick joint(ZG3/8''), which makes it convenient and fast for you to use.
How to Use
1. Connect the oil pipe to other tools.
2. Close the switch valve on the manual pump tightly, and then press the handle up and down.
3. After completing the work, release the switch valve.
Specification
Model: CP-700
Material: Steel
Process: Lathe Machining
Color: Silver
Thread Connection: ZG3/8''
Maximum Output Pressure: 10000Psi/70Mpa
High Pressure Output: 700KG/CM²
Low Pressure Output: 20KG/CM²
Oil Storage: 900cc/54.92cu in
Tubing Length: 2m/6.6ft
Gross Weight: 11kg/24.3lbs
Product Size: 50*10*16cm/19.68*3.94*6.3in
Package Size: 65.5*18.5*19cm/25.8*7.3*7.5in
Package Included
1 * Manual Hydraulic Pump
1 * English Instruction
1* Pressure Guage
| Brand Name | Eapmic |
|---|---|
| Part Number | 00001 |
