GaiRen 3/4” Heim Joints Rod End Kit, 750” Chromoly Joints Panhard kit Right and Left Hand Thread (4 Pair)
$119.95
- 【Rod End Heim Joint Kit】4 right hand thread and 4 Left hand thread Heim set along with jam nut spacers that are zinc coated to offer more durability and tube adapter.
- 【Max Load Capacity】The panhard rod end kits are heat treated and hard chrome plated to provide a longer use. 28,000 Pound static load rating for heavy-duty performance.
- 【Adaptability】The rod end is with 3/4” shaft with 16tpi. 3/4” bore is the strongest way to make this heim. Fits Tube Size: 1 1/4" OD.x .120" Wall x 1.01"ID. Mounting width is 1-7/8".
- 【Widely Use】The 3/4 rod ends heim joint kit is great for steering and suspension ,traction bars, traction bar kit, panhard bar, steering joints, johnny joint, tie rod, and links joints on hot rods.
- 【Customer Service】Any questions about our Heim Joints Rod End Kit. Please feel free to contact us. We will reply to you as soon as possible within 24 hours.
This product is fulfilled by seller
GaiRen 4 Link 3/4” Adjustable Rod End Heim Joint Kit 4 Pair
Rod End
Thread Size:3/4"-16
Ball Bore: 0.750"
Ball Width: 0.875"
Centerline Length: 2.875"
Thread Length: 1.750"
Load rating capacity: 28,081 lbs
3/4 Bung
Thread Size: 3/4"-16
Fits Tube Size: 1 1/4" OD.x .120" Wall x 1.01"ID.
High Misalignment Spacer
Thread Size:3/4"-5/8"
Jam Nut
Thread:3/4"-16
Width: 1.125"
Height: 0.446"
Carbon Steel, Silver Zinc Plated
Package List
- 4 x Right hand Rod End
- 4 x Left hand Rod End
- 4 x Right hand 3/4 Bung
- 4 x Left hand 3/4 Bung
- 4 x Right hand Jam Nut
- 4 x Left hand Jam Nut
- 16 x High Misalignment Spacer
| Brand Name | GaiRen |
|---|---|
| Part Number | 3/4'' Heim Joint |
