40X-2500X LED Lab Binocular Compound Microscope with 3D-Stage

Easy to attach a microscope camera or digital imager.
Adjustable interpupillary distance.
Adjustable ocular diopter.
Variable intensity illumination.
Coaxial coarse and adjustment.

Focusing knobs are on both sides
Stage upward moving lock protects objectives and slides
Stain-resistant layer mechanical stage
Rack and pinion adjustment condenser
Specifications :
Eyepieces: widefield, WF10X and WF25X
Objectives: Achromatic DIN 4X, 10X, 40X(S), 100X(S, Oil)
: 30 degree inclined 360 degree swiveling binocular
Interpupillary distance: 2-1/8" - 3-1/8" (53mm - 77mm)
Adjustable ocular diopter
Nosepiece: revolving quadruple
Mechanical Stage: 3-D layer
- Size: 4-5/8" x 5" (118mm x 127mm)
- Travel Range (X-Y): 70mm x 21mm
Condenser: NA1.25 Abbe condenser with iris diaphragm
Illumination: LED light, transmitted, intensity adjustable, GS and CE approved
Focusing: coaxial coarse & knobs on both sides
Power Supply: 100-240VAC, 50/60Hz, AC/DC adapter (UL approved) Included
Dimension: 11" x 7" x 13-3/4" (280mm x 178mm x 350mm)

Packing List :
Binocular Microscope
Microscope Body Frame with Layer Mechanical Stage and LED Illumination
Four DIN Standard Objectives, 4X, 10X, 40X and 100X
Pair of Widefield 10X Eyepieces
Pair of Widefield 25X Eyepieces
Color Filter
Dust Cover
User's Manual Download
