HD-SDI Fiber Extender 1080P 30HZ, HD Optical Transceiver Mini SDI Over Fiber Uncompressed Video Converter (Without SFP Modules) Up to 20km Over Single-Mode Fiber Type-C 5V SDI Fiber Converter
- HD-SDI Video: The SDI Fiber extender supports HD/SDI-SDI with 8-channel audio embeded, Automatic reclocking 270Mbit/s - 1.48Gbit/s.
- Uncompressed Transmission: HD video converter can transmit 1080P 30Hz resolution up to 20km over single-mode fiber cable and up to 550m over multimode fiber.
- Compact and Small: Only 3.74*1.06*0.71 inches, the SDI fiber converter is very mini and can install in the cameras. Easy to use and not taking up space.
- Aluminum Alloy Case: Mini SDI converter is made of hard aluminum material, sturdy and not easily corroded. Plug and play, EMI/RFI Resistant.
- Open SFP Slot: The SDI over fiber converter can be used 1.25G SFP Modules, single mode 1310/1550nm or multimode 850nm.
Overview：
The Zhpuostd mini HD-SDI Fiber optic Converter supports 1-channel HD-SDI video (embedded audio), supports plug and play, is EMI/RFI resistant, 1080P 30HZ without compression and damage. Its high compatibility supports automatic matching devices, and the long distance transmission of a single mode can reach 20 km.
Features：
- Each channel includes 8-channel audio embedded
- Directly compatible with HD-SDI camera systems
- Hot swap and hot plug
- Handle all Pathological patterns, fully digital non-compression broadcast level transmission
- LED Status Indication tomonitor the working conditions
- Super optic dynamic rangeand free of adjustment
- Automatic cable equalization to ensure signal integrity
- Long transmission capability at least 20 km
specification：
Fiber interface：Simplex LC
Video interface：BNC
Signal Category:HD-SDI Signal
Video SDI standard：270Mbps (SD-SDI)/ 1.485Gbps (HD-SDI)
SDI format support：625/25PAL; 525/29.97NTSC; 525/23.98NTSC;720p50; 720p59.94; 1080P23.98/24/30; 1080i 23/24/30/50/59.94
Power adaptor：DC 5~25V
Power Consumption: ＜2W
Dimensions (LxWxH): 77x 28x 18 (mm) 3.03、1.10、0.71inch
Weight: 0.1kg
Operating Temperature: -10℃～＋60℃
Video input/output resistance: 75Ω
Technical standard: SMPTE
Power supply mode: External power supply Type-C, power supplyby charging bank
What's inside?
One SDI-IN Transmitter
One SDI-OUT Receiver
Two Type-C 5V Power Adapter
One Mini HD SDI Optical Terminal User’s Manual
Warm Tip:
SDI-OUT:Connect the SDI display with sdi cable .
5V DC: Plug the 5V DC power supply into the unit.
SDI-IN: Connect the SDI camera with sdi cable .<
| Brand Name | Zhpuostd |
|---|---|
| Part Number | 00001 |
