DB9 Serial RS232 to RJ12 6P6C Adapter Cable for APC PDU 940-0144A
$0.00
- DB9 to RJ12/6P6C Serial Cable for APC PDU 940-0144A
- DB9 serial to RJ12 RS232 to RJ12 adapter for APC PDU cable 940-0144A
- APC Rack PDU (AP78xx, AP79xx, AP86xx, AP88xx, AP89xx) and 2G Rack Automatic Transfer Switches (AP7752, AP7752, AP7730, AP7732, AP7721, AP7723)
- Set 9600 bps, 8 data bits, no parity, 1 stop bit, and no flow control to communicate.Apply the port settings to establish the connection. Press 3-5 times to display the username prompt. Use the default username and password of apc
- Lenth:6feet , Package: 1 x DB9 to RJ12 6P6C Serial Cable for APC PDU 940-0144A
This product is fulfilled by seller
DB9 serial to RJ12 6P6C RS232 adapter for APC PDU cable 940-0144A
APC Rack PDU (AP78xx, AP79xx, AP86xx, AP88xx, AP89xx) and 2G Rack Automatic Transfer Switches (AP7752, AP7752, AP7730, AP7732, AP7721, AP7723)
Compatible with APC part 940-0144A
RJ11/RJ12 to DB9. Compatible with Rack PDU (AP78xx, AP79xx, AP86xx, AP88xx, AP89xx) and 2G Rack Automatic Transfer Switches (AP7752, AP7752, AP7730, AP7732, AP7721, AP7723).
APC part 940-0144A
APC pins 1 and 6 are usually not connected
Set 9600 bps, 8 data bits, no parity, 1 stop bit, and no flow control to communicate.
Apply the port settings to establish the connection.
Press 3-5 times to display the username prompt. Use the default username and password of apc
It is possible to use RJ11 plug that has only the middle 4 pins (2,3,4,5). connected APC pins 2,3, and 4 only and it workes perfect.
Package: 1 x DB9 to RJ12 6P6C Serial Cable for APC PDU 940-0144A
APC Rack PDU (AP78xx, AP79xx, AP86xx, AP88xx, AP89xx) and 2G Rack Automatic Transfer Switches (AP7752, AP7752, AP7730, AP7732, AP7721, AP7723)
Compatible with APC part 940-0144A
RJ11/RJ12 to DB9. Compatible with Rack PDU (AP78xx, AP79xx, AP86xx, AP88xx, AP89xx) and 2G Rack Automatic Transfer Switches (AP7752, AP7752, AP7730, AP7732, AP7721, AP7723).
APC part 940-0144A
APC pins 1 and 6 are usually not connected
Set 9600 bps, 8 data bits, no parity, 1 stop bit, and no flow control to communicate.
Apply the port settings to establish the connection.
Press 3-5 times to display the username prompt. Use the default username and password of apc
It is possible to use RJ11 plug that has only the middle 4 pins (2,3,4,5). connected APC pins 2,3, and 4 only and it workes perfect.
Package: 1 x DB9 to RJ12 6P6C Serial Cable for APC PDU 940-0144A
| Brand Name | Suamdoen |
|---|---|
| Part Number | SM-103 |
| Data Transfer Rate | 9600.000000 |
| Cable Length Decimal Value | 6.000000 |
| Cable Length String Value | 6 feet |
| Cable Length Unit | Feet |
