uxcell Pneumatic Tubing Air Brake Hose Air Line Nylon Tube Pipe 1/8''ID x 3/16''OD x 32.8ft Black
$22.74
- Specification: ID x OD: 3mm x5mm/0.12''x0.2''; Length: 10M/32.8ft; Package: 1 x Nylon Tubing. Working Pressure: 3MPa/435psi; Operating temperature: -40 to 248℉.
- Material: PA12 Nylon is a good electrical insulator, it can be used to transport compressed air, water, etc.
- Advantage: PA12 Nylon is a strong and lightweight material with stable size, semi-rigid properties, excellent anti-kink and good pressure resistance.
- Easy Operation: PA12 Nylon tubing can be used with standard fittings for simple installation. It can keep a flexible and long service life.
- Application: Widely used in air, water, petroleum pipelines, hydraulic transmission systems, irrigation control systems, clutch hose, etc.
This product is fulfilled by seller
Specifications:
Material: Nylon PA12
Color: Black
Length: 10M/32.8ft
ID x OD: 3mm x5mm/0.12''x0.2''
Working Pressure: 3MPa/435psi
Operating temperature: -40 to 248℉
Density: 1.02g/cm3
Tensile strength: >60MPa
Bending strength: 90 MPa
Melting Point: 338~356℉
Package Content: 1 x Nylon Tubing
Features:
1. Nylon PA12 is a strong and lightweight material with stable size, it has a very low moisture absorption rate compared to other nylon.
2. By not absorbing moisture, nylon PA12 will remain more flexible, which in turn extends its service life.
3. Nylon tubing can be used with standard push-to-connect fittings and compression fittings for simple installation.
4. Because of its semi-rigid properties, nylon tubing offers a thinner tube wall providing higher rates and working pressure.
5. It can be used in the -40 to 248℉ temperature environment, so the nylon tube can be used to transport compressed air, water.
6. Widely used in air, water, lubricants, instrument lines, irrigation control systems, textile mills, vacuum systems, air conditioning systems, And hydraulic brake systems, oscillation insulators, and other industries.
Material: Nylon PA12
Color: Black
Length: 10M/32.8ft
ID x OD: 3mm x5mm/0.12''x0.2''
Working Pressure: 3MPa/435psi
Operating temperature: -40 to 248℉
Density: 1.02g/cm3
Tensile strength: >60MPa
Bending strength: 90 MPa
Melting Point: 338~356℉
Package Content: 1 x Nylon Tubing
Features:
1. Nylon PA12 is a strong and lightweight material with stable size, it has a very low moisture absorption rate compared to other nylon.
2. By not absorbing moisture, nylon PA12 will remain more flexible, which in turn extends its service life.
3. Nylon tubing can be used with standard push-to-connect fittings and compression fittings for simple installation.
4. Because of its semi-rigid properties, nylon tubing offers a thinner tube wall providing higher rates and working pressure.
5. It can be used in the -40 to 248℉ temperature environment, so the nylon tube can be used to transport compressed air, water.
6. Widely used in air, water, lubricants, instrument lines, irrigation control systems, textile mills, vacuum systems, air conditioning systems, And hydraulic brake systems, oscillation insulators, and other industries.
| Brand Name | uxcell |
|---|---|
| Part Number | a20110300ux0186 |
| Maximum Pressure | 435.000000 |
| Inside Diameter Unit | Millimeters |
| Inside Diameter Decimal Value | 3.000000 |
| Nominal Wall Thickness | 1.02 month |
| Outside Diameter Unit | Inches |
| Outside Diameter Decimal Value | 0.200000 |
| Item Length Unit | Inches |
| Item Length Longer Edge | 393.600000 |
| Item Width Unit | Inches |
| Item Width Shorter Edge | 0.200000 |
| Item Length End to End | 32.800000 |
| California Proposition 65 Warning Type | Chemical |
