Wiistar 3G SDI to AV Converter BNC to RCA Audio Scaler with SDI Signal Loopout Support Convert HD-SDI,3G-SDI Signal for TV
$70.99
- Convert 3G&HD SDI to composite RCA video+L/R, with SDI signal loopout;Input port: 1xBNC(HD/3G-SDI) ; Output port: 3xRCA(CVBS, L/R), 1xBNC(HD/3G-SDI)
- SDI input Format:3G-SDI:SMPTE 424M ; HD-SDI:SMPTE 292M
- AV output resolution :480i/576i/480P/576P
- Conversion from SMPTE 425M level B to level A 1080p 50/60 4 : 2 : 2 10-bit ; Easy to install, plug and play
- SDI support HD-SDI,3G-SDI, NOT support SD-SDI
This product is fulfilled by seller
Introduction:
This SDI to AV(CVBS) converter allows HD-SDI and 3G-SDI signals to be shown on normal TV while ensuring high bit rates of 2.970Gbit/s to give you fast signal transmission without any loss, and thereby expensive monitor can be replaced by normal TV. It also support L/R analog audio output and can be connected to sound system to get perfect music.
Features:
Operation at 2.970Gbit/s, 2.970/1.001Gbit/s, 1.485Gbit/s,1.485/1.001Gbit/s
Auto video mode detection(3G/HD)
Conversion from SMPTE 425M level B to level A 1080p 50/60 4 : 2 : 2 10-bit Connect with other units to extend your signal over long distances
2CH analog audio output
Supports signal transmission distances up to 200M for HD signals and 100M for 3G signals
Note: Cable tested with Belden 1694A. Operation distances may vary if used with another type of cable.
Specifications:
SMPTE Standard: 425M Level A&B, 424M, 292M, 259M-C
SDI Transmission Rates: 2.970Gbit/s and 2.970/1.001Gbit/s
SDI in Resolution:
HD: 720p@50/60, 1080i@50/60.
3G: 1080p@24/25/30/50/60
CVBS Output Resolution: PAL/NTSC-M(optional)
Input port: 1xBNC(HD/3G-SDI)
Output port: 3xRCA(CVBS, L/R)
Power Supply: DC 5-12V
Dimension(mm): 95(L)x65(W)x28(H)
Operating Temperature: 0℃~40℃/32℉~104℉
Storage Temperature: -20℃~60℃/-4℉~140℉
Relative Humidity: 20~90%RH(Non-condensing)
Power Consumption(Max): 2W
Package Contents:
Main Unit(3G SDI to AV Converter)*1
US Standard Power Adapter*1
User Manual*1
This SDI to AV(CVBS) converter allows HD-SDI and 3G-SDI signals to be shown on normal TV while ensuring high bit rates of 2.970Gbit/s to give you fast signal transmission without any loss, and thereby expensive monitor can be replaced by normal TV. It also support L/R analog audio output and can be connected to sound system to get perfect music.
Features:
Operation at 2.970Gbit/s, 2.970/1.001Gbit/s, 1.485Gbit/s,1.485/1.001Gbit/s
Auto video mode detection(3G/HD)
Conversion from SMPTE 425M level B to level A 1080p 50/60 4 : 2 : 2 10-bit Connect with other units to extend your signal over long distances
2CH analog audio output
Supports signal transmission distances up to 200M for HD signals and 100M for 3G signals
Note: Cable tested with Belden 1694A. Operation distances may vary if used with another type of cable.
Specifications:
SMPTE Standard: 425M Level A&B, 424M, 292M, 259M-C
SDI Transmission Rates: 2.970Gbit/s and 2.970/1.001Gbit/s
SDI in Resolution:
HD: 720p@50/60, 1080i@50/60.
3G: 1080p@24/25/30/50/60
CVBS Output Resolution: PAL/NTSC-M(optional)
Input port: 1xBNC(HD/3G-SDI)
Output port: 3xRCA(CVBS, L/R)
Power Supply: DC 5-12V
Dimension(mm): 95(L)x65(W)x28(H)
Operating Temperature: 0℃~40℃/32℉~104℉
Storage Temperature: -20℃~60℃/-4℉~140℉
Relative Humidity: 20~90%RH(Non-condensing)
Power Consumption(Max): 2W
Package Contents:
Main Unit(3G SDI to AV Converter)*1
US Standard Power Adapter*1
User Manual*1
| Brand Name | Wiistar |
|---|---|
| Part Number | 43237-187380 |
| Current Rating Unit | Amps |
| Current Rating | 0.500000 |
| Input Voltage Unit | Volts |
| Input Voltage | 12.000000 |
| Nominal Power Unit | Watts |
| Nominal Power | 2.000000 |
