PF10000632183
In stock
Pc Accessories - Connectors Pro 34P 10-Pack 1.27mm 0.05" Pitch Mini Dual Rows IDC Female Sockets Terminates to 0.635mm 0.025" Flat Ribbon Cable (FC-34P-10PK)
$25.95
- Price is for 10-Pack 34P 1.27mm Sockets
- 2X17 34 PINS IDC SOCKET-RECEPTACLE 0.05" x 0.05" (1.27mm x 1.27mm) DUAL-ROW Sockets
- FEMALE CONNECTOR WITH POLARIZING CENTER BUMP, NO STRAIN RELIEF
- Specifications: Current Rating: 1AMP; Operation Temperature: -40°C to +105°C ; Contact Resistance: 20mΩ Max. at DC 100mA ; Insulation Resistance: 1000MΩ Min. at 500V DC
- Mates with 1.27 mm (0.05") Pitch Headers; Terminations to 0.635 mm (0.025") pitch FLAT RIBBON CABLE
This product is fulfilled by seller
PRICE is for 10-PACK. Dual-Row 127mm Socket, IDC, 34 Position, IDC Flat Ribbon crimp Connectors These connectors mate with any 1.27mm spaced dual-row pin headers. The insulation displacement (IDC) contacts on these connectors allow them to be quickly and easily crimped onto flat ribbon cable. NUMBER OF PINS: 34P 2X173 IDC SOCKET-RECEPTACLE 1.27mm x 1.27mm DUAL ROW IDC FEMALE CONNECTOR FEMALE CONNECTOR WITH POLARIZING CENTER BUMP, NO STRAIN RELIEF SELECTIVE GOLD PLATING MATES WITH 1.27 mm PITCH Headers and TERMINATES to 0.635mm (0.025") pitch FLAT RIBBON CABLE
| Brand Name | Connectors Pro |
|---|---|
| Part Number | 127-FC34P-10PK |
| Maximum Voltage Unit | Volts |
| Maximum Voltage | 500.000000 |
