Hanchen Wrist Strap Tester Antistatic Foot Strap Tester Whole Body Tester Access Control System Static Tester for Antistatic Equipment (110V, Set 1（Without Access Control Signal Reception)

Hanchen

Description
This Electro-Static discharge tester is designed according to the standards as follows:
*American National Standard
ANSI-ESD-S20.20-2014 Electro-Static discharge Standard
*Electronic Industry Standard of the People's Republic of China
SJ/T 10694-2006 General Specification for Anti-static Detection of Electronic Products Manufacturing and Application Systems
*National Military Standard of the People's Republic of China
GJB 3007A-2009 Technical Requirements for Anti-static Workspace
Parameters
Tester
Access control signal reception: NO
Tester Size: 6.5*3.7*1.5in
Wrist Strap Setting: 750kΩ-10MΩ
Set 1 (Tester + bracket + pedal)
Access control signal reception: NO
Tester Size: 6.5*3.7*1.5in
Pedal Size: 16.5*15.7*0.7in
Adjustable range of bracket: >5.9in
Left Shoe Setting: 750kΩ-100MΩ
Right Shoe Setting: 750kΩ-100MΩ
Wrist Strap Setting: 750kΩ-10MΩ
Test Accuracy: ±10%
Whole Set Weight： 14.3 lb
Set 2 (Tester + bracket + pedal)
Access control signal reception: YES
(Other parameters are the same as Set 1) INSTALLATION OPERATION:
1. Pass the wiring on the pedal from the bottom of the bracket to the top.
2. Use three sets of M8x25mm to fix the bracket and the pedal.
3. Connect the wiring with the corresponding connection port at the bottom of the tester.
4. Align the three holes on the bottom of the tester with the three screw posts on the bracket, and fasten them down.
5. Tighten the bracket lift lock to lock the bracket height.
Note
We provide ONE YEAR warranty for every our customer.
If you have any questions, please feel free to contact us directly. We will give you a reply as soon as possible.
