TUOPUONE LCD-1602 I2C Module Green Color 32 Characters LCD 3.3V/5V Backlight Adjustable
- I2C interface, only two wires are needed for direct control, making it easy to connect to multiple control boards
- Up to 16 X 2 characters can be displayed, supporting functions such as screen scrolling and cursor movement
- Exquisite appearance, fine workmanship, high integration design, stable performance, compact size of 87 * 32 * 13 (mm)
- Onboard AiP-31068L LCD driver and SN-3193 backlight driver IC
- Complete supporting materials and manuals (demos / user manuals)
Overview
Introduction
Our LCD1602 module is controlled via the I2C protocol and is available for platforms such as Raspb Pi, Raspb Pi Pico, ESP32. Compared to traditional parallel interfaces, I2C greatly simplifies wiring and saves GPIO pins, making it ideal for embedded projects and rapid prototyping design.
The display has three optional backlight colors: blue, green, and gray, and users can choose the appropriate background color according to their needs to enhance the display effect or match the project theme.
Features
I2C interface, only two wires are needed for direct control, making it easy to connect to multiple control boards
Up to 16 X 2 characters can be displayed, supporting functions such as screen scrolling and cursor movement
Exquisite appearance, fine workmanship, high integration design, stable performance, compact size of 87 * 32 * 13 (mm)
Onboard AiP-31068L LCD driver and SN-3193 backlight driver IC
Complete supporting materials and manuals (demos / user manuals)
Specifications
Operating Voltage：3.3V/5V
Operating Current：
5V: 26mA
3.3V: 13mA
Communication Interface：I2C
I2C Address：
LCD: 0x7C
LED: 0x6B
Screen Type：LCD
Controller Chip：
LCD: AiP31068L
LED: SN3193
Dimensions：87.0 x 32.0 x 13.0 (mm)
