GEYOPMID Hydraulic Jack for Car, 20t Hydraulic Ram Jack + Cp-180 Hydraulic Hand Pump, Hydraulic Ram Pump Kit 2” Stroke Hydraulic Jack 20 Ton Hydraulic Cylinder Jack with Pressure Gauge
- 【Strong Lifting Force】The mechanism boasts a substantial lifting capacity of 44092 lbs, which enables it to lift heavy objects of significant weight with ease. The impressive lifting force renders it a versatile and efficient option for fulfilling various lifting requirements.
- 【Time and Energy Saving】With portable hydraulic jack, you can lift heavy objects more easily, reducing the risk of manual labor, improving the safety of use, and enhancing efficiency.
- 【Thoughtful Design】Hydraulic car jack can be used in narrower and lower spaces and has a stroke of 2 inches to meet your usage needs. In addition, the large oil storage capacity makes it can be used for a long time, avoiding frequent additions.
- 【Simple Operation】You can tighten the return switch on the hydraulic pump clockwise, press the handle and the jack automatically jacks up. After loosening the return switch, the jack automatically retracts. In addition, the direction of the use of the jack is not restricted and can be used horizontally, or upside down.
- 【Access to More Spaces】Compared to traditional large jacks, this one has a compact body (3.54*4.17 inches), which allows it to work not only in large places but also in narrow and tight spaces.
Specification
Cylinder Model: RSC-1050
Hand Pump Model: CP-180
Color: Green
Shape: Cylinder
Material: Steel
Process: Plastic Spraying
Interface Size: 3/8''
Maximum Output Pressure:700/10000KG/CM2
Output Pressure: High Pressure 60KG/CM2
Length of Oil Pipe: 1m/3.28ft
Total Tonnage: 10T/22046lbs
Stroke: 50mm/2in
Travel: 50min
Collapsed Height: 102mm/4.02in
Extended Height: 152mm/5.98in
Cylinder Jack Size(D*H): 6.4*10.4cm/2.52*4.09inch
Hand Pump Size: 34*10*14cm/13.39*3.94*5.51inch
Package Size: 37.5*22.5*16.5cm/14.76*8.86*6.5inch
Gross Weight: 5.5kg/12.13lbs
Net Weight: 5kg/11.02lbs
Package Included
1* Hydraulic Cylinder Jack
1* Hand Pump
Notes
1. Please use the product on a flat surface, not on soft or rough ground, and do not apply unilateral force to the spindle.
2. If there is a slight oil leak at the interface, you can wrap it with a raw material belt (not included).
3. There is hydraulic oil in the hydraulic pump. After a long time of use, you need to refuel yourself, it is recommended to use No.15 hydraulic oil (not included).
4. Before use, the interface between the jack and the pump should be installed firmly, otherwise it will leak oil. A slight oil leak at the interface is normal.
5. The first time you use it, you need to press the hydraulic pump a few more times to remove the air inside the jack.
6. Please allow the slight color difference caused by the shooting light and 1-3 cm error due to manual measurement, and make sure you do not mind before ordering.
