TQQEPOOL 3D Scanner for 3D Printing, Reverse Engineering, Handheld Scanner with 0.02mm Accuracy, 10 2000mm Scanning Range, 20fps Speed, Manual Turntable for 3D Model, mac OS Wind
$1,399.99
- 0.02mm Precision: scanner enables adopts the state-of-the-art structure-light stereo-matching algorithm and optical design to faithfully reproduce the authentic texture and contours of objects. scanning accuracy up to 0.02mm. Cross-platform (Win, macOS) operation, easy to use.
- Unique Algorithm: Face & body mode is equipped with a unique face mapping algorithm that collects more details, easily scans hair. A human body scan only needs 2 minutes. harmlss to the human body. maintains excellent performance even in sunlight (<30000 lux).
- Collects Small & Big Objects: realizes possibilities of scanning various objects, ranging in size from 10*10*10mm to 2000*2000*2000mm, all covered in one scanner. The scanning distancesrange from 110mm to 1200mm to effectively collects items of versatile sizes.
- Scan Black/Metal Objects Without Spraying Even without scanning spray, you can scan cars, car parts, tires, and other black/metal objects to get the desired model effect.
- Compatibility: It supports multiple data format outputs, OBJ, STL, and PLY. This compatibility with a wide range of CAD, 3D modeling, and design software makes it versatile and suitable for various applications such as modeling, animation, presentation, printing, and design, expanding the possibilities of your scans. 3d scanner is compatible with Mac/Win/IOS Systems.
This product is fulfilled by seller
Specifications
Accuracy: 0.02mm
3D Resolution: 0.05-2mm
Scanning Speed: Up to 20fps
Buttons: Touch
Input Power: 5V 3A
Device Weight: 390g
Color Mapping: YES
Calibration board: Yes
IMU: YES
Audible prompt: Yes
Output Format: OBJ/STL/PLY
Data Interface: Type C/USB3.0/USB2.0
Working Distance: 110mm-1000mm
Min. Scan Volume: 10mmx10mmx10mm
Device Size: 165mmx37mmx59mm
Operating Humidity: 0-90% RH
Operating Temperature -10°℃ to 40℃
Marker Recognition Enhancement: 8 infrared LEDs
Alignment Modes: Geometry/Marker/Texture
Color Supplemental Light: 2 white LEDs
Technology: Infrared structured light
Single Collects Range: 1350x840mm @1000mm
Accuracy: 0.02mm
3D Resolution: 0.05-2mm
Scanning Speed: Up to 20fps
Buttons: Touch
Input Power: 5V 3A
Device Weight: 390g
Color Mapping: YES
Calibration board: Yes
IMU: YES
Audible prompt: Yes
Output Format: OBJ/STL/PLY
Data Interface: Type C/USB3.0/USB2.0
Working Distance: 110mm-1000mm
Min. Scan Volume: 10mmx10mmx10mm
Device Size: 165mmx37mmx59mm
Operating Humidity: 0-90% RH
Operating Temperature -10°℃ to 40℃
Marker Recognition Enhancement: 8 infrared LEDs
Alignment Modes: Geometry/Marker/Texture
Color Supplemental Light: 2 white LEDs
Technology: Infrared structured light
Single Collects Range: 1350x840mm @1000mm
| Brand Name | TQQEPOOL |
|---|---|
| Part Number | TQQEPOOL83ydxinet2 |
