YoungRC 915Mhz 100MW RC Telemetry RC Air and Ground Data Module Telemetry Kit for APM2.6 APM2.8 Pixhawk Flight Controller
- Support for OTG of Android Cellphones, and for computer OTG. Antenna is 5.8G. Very small size and light weight.
- Air data transfer rates up to 250kbps, Transmit power:20dBm (100mW).
- It can be used with standard for APM, for Pixhawk flight controller (for APM 2.6 2.8 Pixhawk 2.4.8 flight controller etc). easy to install and connect.
- Available bi-directional amplifier gain greater range.
- With a standard for TTL UART interface, for HM-TRP wireless module based, with for Si4432 Si1000 8051 microcontroller and wireless modules.
Specifications:
Weight:4g (exclude the antenna)
Frequency band: 915MHZ
Receiver sensitivity: -121 dBm
Transmit power:20dBm (100mW)
Transparent serial link
Air data transfer rates up to 250kbps
MAVLink protocol frame and status reports
Frequency Hopping Spread Spectrum (FHSS)
Adaptive time division multiplexing (TDM)
Support LBT and AFA
Configurable duty cycle
Built-in error correction code (up to 25%can be corrected data bit errors)
Use a small omni-directional antenna up toseveral kilometers
Available bi-directional amplifier gain greater range
Open Source Firmware
AT commands to configure data transmission
RT command remotely configure data transmission
Adaptive traffic control and use APM
HM-TRP wireless module based, with Si4432 Si1000 8051 microcontroller and wireless modules.
100MW Wireless communication distance 800M
Package list:
1 set 915Mhz 100mW Telemetry Module.
| Brand Name | YoungRC |
|---|---|
| Part Number | 915 100mw |
| Manufacturer Minimum Age (MONTHS) | 18.000000 |
| FCC ID | 2AP22-HT03-V3 |
