Uxcell Flange Bearing Sleeve 3/8" Bore x 5/8" OD x 1/2" Length x 3/4" Flange Dia. x 1/8" Flange Thickness Sintered Bronze Bushings
$0.00
- Bore: 3/8", Outside Diameter: 5/8", Length: 1/2", Flange Dia.: 3/4", Flange Thickness: 1/8"
- Lubrication-free. Suitable for high sliding operation
- Good frictional property. Maintenance-free
- Featured with good load capacity and wear resistance performance
- Wide application such as electrical equipment, household equipment, printing machinery and machine tools
This product is fulfilled by seller
Description:
Sintered plain bearings are made of powder-metallurgical tin bronze, which has a large working temperature range from -80 degree Celsius to 120 degrees Celsius.
As good frictional properties as high sliding, Oiled Bearing Sleeves have a small friction coefficient of about 0.12-0.18.
Sintered bronze bushings are most suitable for applications with rotating movements and where self-lubricating properties of the material are a prerequisite.
Specification:
Material: Tin Bronze
Bore Diameter: 3/8" / 9.525mm
Outside Diameter: 5/8" / 15.875mm
Length:1/2" / 12.7mm
Flange Dia.: 3/4" / 19.05mm
Flange Thickness: 1/8" / 3.175mm
Number of Item: 1 Pack
Sintered plain bearings are made of powder-metallurgical tin bronze, which has a large working temperature range from -80 degree Celsius to 120 degrees Celsius.
As good frictional properties as high sliding, Oiled Bearing Sleeves have a small friction coefficient of about 0.12-0.18.
Sintered bronze bushings are most suitable for applications with rotating movements and where self-lubricating properties of the material are a prerequisite.
Specification:
Material: Tin Bronze
Bore Diameter: 3/8" / 9.525mm
Outside Diameter: 5/8" / 15.875mm
Length:1/2" / 12.7mm
Flange Dia.: 3/4" / 19.05mm
Flange Thickness: 1/8" / 3.175mm
Number of Item: 1 Pack
| Brand Name | uxcell |
|---|---|
| Part Number | a19032100ux0052 |
| Item Thickness Unit | Inches |
| Bearing Number | 1 |
| Bore Diameter Unit | Inches |
| Outside Diameter Unit | Inches |
| California Proposition 65 Warning Type | Chemical |
