ELING GPS Speedometer 200MPH Speed Gauge Odometer Trip Meter 3-3/8" with 8-Color Backlight

Product Features:
-Suitable for all cars, tractors, vans, motorcycle, racing, etc.
-The signal comes directly from the satellite signal receiver (GPS Speed Sensor)
-The gauge has the advantages of high precision, quick location confirmation and short start up time.
-IP67 waterproof and dustproof grade
-Stepper motors used for full range of stepping gauges, great feature with its less power consumption, longer life, higher precision, etc.
-With curved glass (with anti-fogging function)
-With ultra-wide working voltage design( long-term operating voltage: 9-32V, Maximum up to: 36V (≤ 1 min)).

Technical Data:
-Fixing dimension: 85mm(3-3/8")
-Indicating Range:0-200MPH
-Faceplate Color: black faceplate with stainless Steel. If you need other faceplate, pls. search for B07KPG73QQ (BN) and B07KPH21ZJ (WS)
-Working Voltage: 9-32VDC(12VDC/24VDC)
-Backlight: Red Green Blue White Yellow Orange Purple Light Green or automatic
-Functions:
Needle shows current speed;
Led window shows: TRIP/COG(choose anyone) and ODO
TRIP---TRIP01(Default) one-trip mileage which will come back to 0 after power off, TRIP02 one-trip mileage which accumulates after power off, but you can press “Set” button for 3-5 seconds to clear the data.
COG---course over ground
ODO---recording total mileages automatically and cannot be reset
-Connection: Blue wire--Negative/Ground, Red wire--Positive, Orange wire--Positive(lighting wire)
-After connection, it takes about 30 seconds to get signal in the first time, but less than 3 seconds after that. It gets quicker under a clear view of the sky. Sometimes if signal is missing, pls. reconnect all wires and restart it.

Package Includes:
1x GPS speedometer
1x GPS Speed Sensor
1x Multi-plug socket
1x Installation Instruction
