SHANGZHAOYUAN LGA 2011-3 Motherboard X99 for Intel E5 V3/V4 and 5th/6th gen Core i7 Series Processors, DDR4 Slots max 256GB, NVME M.2, NGFF M.2,WiFi M.2, SATA 6Gbps, Gb LAN (E5 MR9S, ATX)
- LGA 2011-3 Socket: This Intel X99 motherboard supports Intel 5th/6th gen Core i7 processors and Xeon E5 V3/V4 series processors. (Eg. E5-1660 V3, E5-2660 V3, E5-2650 V3, E5-2640 V3, E5-2620 V3, E5-1620 V4, E5-2690 V4, E5-2667 V4, E5-2650 V4, E5-2680 V4, i7-5960X, i7-6900K, etc.)
- 4-Channel DDR4 Slots: The memory slots of this LGA2011-3 motherboard are 4-channel design, compatible with ECC and non-ECC DDR4 memory, the maximum capacity is 8*32GB. And the placa madre supports 2133/2400MHz memory clock speed
- High-speed M.2 Slots: This ATX motherboard is equipped with NVME M.2 (PCIe 3.0 X4 bandwidth) and NGFF/SATA M.2 (SATA 6Gbps) slots, of which NVME M.2 maximum speed Up to 3600M/S
- PCIe Expansion Slots: The server motherboard is equipped with 2 * PCIe 3.0 X16 slots, 1 * PCIe 3.0 X4 slots(with steel casing) and 2 * PCIe 2.0 X1 slots. Each lane can support a rate of 8Gbps, and the rate of the X16 slot can reach 128Gbps
- Other Powerful Components: The gaming motherboard with 8-phase power supply, 8-layer PCB, one-touch on/off and one-touch reboot, VRM cooling fan, digital diagnostic card, and aluminum heat sink. Note: the latest version of the motherboard does not have a buzzer
- Package Includes: 1*LGA 2011-v3 cooler bracket, 2*SATA cable, 1*motherboard. IMPORTANT: The package does not contain a user manual. If you need the manual, please download it from the product description page or ask us on Amazon to get it. And the motherboard does not include a CR2032 battery, please purchase one yourself
- Warm Tips: If no display, no boot, no screen, no network card, no sound card, etc., please ask us on Amazon for help. It is recommend driver download: Driver Talent, or use Win 10 system, it can help you solve all the driver problems. This motherboard does not support core graphics and an external graphics card must be installed
SHANGZHAOYUAN E5 MR9S Motherboard, X99 LGA 2011-V3 Motherboard for Intel 5th/6th i7, XEON E5 V3/V4 series CPUs
Common Problems:
1. The diagnostic card appears on the “FF” code, may be the CPU is incompatible, CPU pins on the foreign body or power supply is not properly connected. You can use an eraser to wipe the metal fingers of the CPU to ensure cleanliness.
2. If the code “B7”, “B9”, “53”, “B0”, this is the motherboard did not Detect the memory problem. You can unplug the memory several times or use an eraser to wipe the metal fingers of the memory to solve the problem.
3. The installation of Win 10 system can avoid a lot of unnecessary trouble, without having to download any drivers on their own to use the computer normally.
Tips:
1. If you need the motherboard to enter the BIOS, please press the “Del” key continuously after pressing the boot button. Please don't wait until the boot logo screen appears on the computer screen, because it's already too late.
2. If you need to enter the Quick Start Program, press the power on button and then press F11 continuously.
E5 MR9S ATX Motherboard Specification:
Main chipset: Intel B85
Motherboard structure: ATX
CPU socket: Intel LGA 2011-3 (Support Intel 5th/6th i7, XEON E5 V3/V4)
Memory slot: DDR4 (Support 2400/2133 MHz, ECC and Non-ECC)
Maximum memory: 256GB
PCIe slot: 2 * PCIe 3.0 X16 slots, 1 * PCIe 3.0 X4 slots and 2 * PCIe 2.0 X1 slots.
Storage interface: 4 * SATA3.0, 2 * SATA2.0, 1 * NVME M.2, 1 * NGFF M.2.
USB Port: 2 * USB 3.0, 6 * USB 2.0
Onboard LAN: 1 * Gigabit LAN
Power connector: 24pin + 8pin DC
Overclock: Not support
Material: 8-layer PCB
Motherboard size: 303mm x244mm
Package list: 1*LGA2011-3 cooler bracket, 2*SATA cable, 1*small cooling fan, 1*motherboard.
| Brand Name | SHANGZHAOYUAN |
|---|---|
| Part Number | 00001 |
| Platform | Windows |
| Compatible Processors |
|
| Memory Storage Capacity Unit | GB |
| Memory Storage Capacity | 256.000000 |
| Memory Clock Speed | 2400.000000 |
| Memory Clock Speed Unit | MHz |
| RAM Memory Maximum Size Unit | GB |
| RAM Memory Maximum Size | 256.000000 |
| Total PCIe Ports | 5 |
| Item Height base to top | 244.000000 |
| Item Length Longer Edge | 303.000000 |
| Item Width Shorter Edge | 244.000000 |
