IDC-34 DIN Rail Mounted Interface Module.

Be the first to review this product

$0.00

FR-4 fiber glass PCB, dual copper layers.
Rated voltage - 300V,Rated current - 10A.
Wire range - 24-12AWG.
Screws - M3,steel,Zinc plating color.
Pin header and Cage - Gilded(3U).

This product is fulfilled by seller

Skip to the beginning of the images gallery

Details

More Information

Reviews

Questions

IDC-34 DIN Rail Mounted Interface Module. IDC pin pitch 2.54mm/0.1" male header connector. Pitch 5.0mm/0.197" screw terminal block. Din rail mountable - for width 35 / 32 / 15mm rails. Din mount case can be taken apart for panel mount use. FR-4 fiber glass PCB, dual copper layers. PCB Dimensions: 72.5 x105mm(W x L). External dimensions: 87 x 107x 54mm(W x L x H). 100% new, never used. Terminal block specifications: Pitch - 5.0mm. Rated voltage - 300V. Rated current - 10A. Wire range - 24-12AWG. Strip length - 5mm. Screws - M3,steel,Zinc plating color. Pin header and Cage - Gilded(3U).

More Information
Brand Name	WELL LONG
Part Number	00001
