Hydraulic Hand Pump 10T Hydraulic Ram Pump Low Profile Hydraulic Jack with CP-180 Hydraulic Hand Pump 0.47" Stroke for Machinery Shipbuilding
- Large Load Tonnage: The high hardness material of this hydraulic jack makes it able to load a tonnage of 10T/22.46.22 lbs, which is large enough to lift many items to meet your work needs.
- Strong and Durable: The hydraulic jack and pump are made of high hardness and high-quality steel material with the sprayed surface treatment. This makes the item less prone to rust and very durable, with long service life.
- Smooth Lacquer Surface &Anti-Dust Cover: The interface part of the jack is a threaded ZG3/8 joint with a steel ball inside that can prevent reverse oil leakage. The interface dust cover can also prevent impurities and dust from entering. This can make the jack's service life longer.
- Ergonomic Design: The handle of the pump is a very ergonomic design. It is smoother and more comfortable to hold while you are working. You will not feel fatigued even after long hours of use, giving you great comfort.
- High Stability: The pump has support feet on both sides to place it more stable. It will not shake freely when using it.
Details
Stop Ring: There is a stop ring under the spindle that can play a protective role when the spindle is raised to prevent breakage and damage. It is safer for you to use it.
Chrome-plated Surface: The surface of the spindle is chrome-plated, which makes it smoother and can extend the service life of the spindle.
On/Off Knob: There is a knob on the pump head for controlling the jack. Tune it to OFF to lift the jack. When tuned to ON, the jack will restart. This knob can make the operation more convenient and safer.
Anti-slip Circles: There are raised anti-slip circles above the spindle that can play an anti-slip effect to ensure that the objects placed on it will not slide casually. This makes it safer for you to use.
Convex Pattern: The handle of the pump has a convex pattern design, which can play a good anti-slip effect. You can grip it more firmly when using it, providing better force.
Specifications
Color: Yellow + Black
Jack Model: RSC-1050
Pump Model: CP-180
Product Material: Steel
Oil Pipe Material: Rubber
Surface Treatment: Spraying
Spindle Surface Treatment: Chrome Plated
Jack Load Tonnage: 10T/22.46.22 lbs
Jack Stroke: 5cm/1.97"
Jack Body Height: 10.2cm/4.02"
Jack Extended Height: 15.2cm/5.98"
Jack Size: 14*7.5*10cm/5.6*3*4"
Jack Oil Storage Capacity: 72cc
Jack Weight: 2.5kg/5.51 lbs
Pump Max Pressure: 70 MPa
Pump Weight: 3kg/6.61 lbs
Gross Weight: 6.5kg/14.33 lbs
Package Size: 38.5*22.5*17cm/15.16*8.86*6.7"
| Brand Name | FireLeaves |
|---|---|
| Part Number | YYQJ-1 |
| Minimum Height Unit | Centimeters |
| Minimum Height | 15.200000 |
