Fielect 2Pcs KSD301 Thermostat 125°C/257°F Normally Closed N.C Snap Disc Limit Control Switch Microwave Thermostat Thermal Switch

KSD301 Temperature Control Switch

Technical Parameters:

Product Name : Thermostat Temperature Control Switch
Model: KSD301
Action Temperature: 125°C
Action Type: N.C (Normally Closed)
Rated Voltage/Current : 250V 10A
Pin Width : 6.3mm/0.25inch
Contact Life: More than 50,000 times (action times)
Electrical Strength: AC50Hz, 2000V/min no breakdown and arc phenomenon

Product Description :

1.Normally Closed: The original state of temperature control switch contact is closed, and open when the temperature sensing exceeds the rated temperature
2.Feature: Double metal chip, speed dynamic type, sensitive, reliable, stable action temperature, long service life, no arc phenomenon
3.Advantage: General purpose, automatic reset, low cost, large capacity, minute current thermostats

Please Note:

1.Do not collapse, loosen or deform the top of cover surface during installation to avoid affecting performance
2.Do not allow liquid to penetrate into the interior of the thermostat or crack the housing
3.The thermostat should be stored in a warehouse with RH less than 90% and ambient temperature less than 40 ℃, which is ventilated, clean, dry

Package Content :
2Pcs x KSD301 Thermost
