BuufuS 10T Hydraulic Cylinder Jack Porta Power Ram, Single Acting Lifting Cylinders with Anti Slip Circles Manual Hydraulic Jack for Vehicle Maintenance Mechanical Installation
- Large Load Tonnage: The high hardness material of this jack makes it able to load a tonnage of 10T/22.46.22 lbs, which is large enough to lift many items to meet your work needs.
- Strong and Durable: The jack and pump are made of high hardness and high quality steel material with the sprayed surface treatment. This makes the item less prone to rust and very durable, with long service life.
- Multi-angle Use: You can choose vertical, horizontal or inverted placement orientation according to space requirements. All of these angles can achieve a lift.
- Anti leakage and Dustproof: The interface part of the jack is a threaded ZG3/8 joint with a steel ball inside. The interface dust cover can also prevent dust from entering. This can make the jack's service life longer.
- High Safety: The anti slip circle on the spindle can ensure that the items placed are more stable. The stop ring can prevent the jack from damaging when the load is applied.
This manual hydraulic jack is made of high-quality steel, which is strong, durable and not easy to deform. It has a load tonnage of 10T/22.46.22 lbs. You need to press the pump handle to jack up heavier items easily. This manual hydraulic jack is very labor saving and convenient to use. It is also a good helper when you work.
Details
- Stop Ring: There is a stop ring under the spindle that can play a protective role when the spindle is raised to prevent damage.
- On/Off Knob: There is a knob on the pump head for controlling the jack. Tune it to OFF to lift the jack. When tuned to ON, the jack will restart.
- Anti-slip Circles: There are raised anti-slip circles above the spindle that can play an anti-slip effect to ensure that the objects placed on it will not slide casually. This makes it safer for you to use.
Application
It is often used in power, chemical, steel, bridges and other industries. It is suitable for railway vehicle maintenance, mechanical installation, construction engineering support, etc.
Specifications
Color: Yellow Black
Pump Model: CP-180
Product Material: Steel
Spindle Surface Treatment: Chrome Plated
Jack Load Tonnage: 10T/22.46.22 lbs
Jack Stroke: 5cm/1.97"
Jack Body Height: 10.2cm/4.02"
Jack Extended Height: 15.2cm/5.98"
Jack Size: 14*7.5*10cm/5.6*3*4"
Jack Weight: 2.5kg/5.51 lbs
Pump Max Pressure: 70 MPa
Pump Weight: 3kg/6.61 lbs
Gross Weight: 6.5kg/14.33 lbs
Package Size: 38.5*22.5*17cm/15.16*8.86*6.7"
How to Use
1.Open the interface cover of the jack to connect with the pump's pipe interface and tighten the screw.
2.Turn the knob of the pump to OFF.
3.Place the jack under the object to be lifted and press the pump handle up and down to start working.
4.After the object is lifted, turn the knob to ON, and the jack will restart.
Notes
1.Please use this item on hard and flat ground.
2.Please do not exceed the load capacity of the jack.
3.Please stop immediately when you see the stop line.
| Brand Name | BuufuS |
|---|---|
| Part Number | 1 |
| Load Capacity | 10 |
