Ersa EASY ARM 1 - Single Input Fume Extractor

Ersa EASY ARM 1 Single input fume extractorArm/nozzle sold separately Effective 3-stage filter system - 99.95% filter degree110 m³/h air flowSmall footprint – 10 x 10 x 18.5” (L x W x H) Single Input Fume Extractor The Ersa EASY ARM 1 and EASY ARM 2 solder fume extractors stand out with high suction power, efficient filter performance and super silent operation. The exhaust volume per arm is 110 m³/h. Both are equipped with filters that clean the process air in three stages: The pre-filter absorbs dust and big particlesThe combined filter separates microparticles that occur during soldering and absorbs dangerous gas molecules in the incorporated activated carbon filterUsers can choose between a system with one exhaust arm–the EASY ARM 1–and a unit with two exhaust arms–the EASY ARM 2. Both units can be mounted individually by means of their table clamp, and exhaust power is set independently for each extraction arm at the touch of a button. The EASY ARM 1 and EASY ARM 2 use an identical pre-filter and combined filter. Optical and acoustical signals inform the operator when filters have to be exchanged.A wide range of exhaust arms and nozzles for all applications are available so that the user will find the proper solution for his requirements. Please note, arms and nozzles are sold separately.For energy saving purposes and to extend filter lifetime, both units can be connected with Ersa i-CON soldering stations or a standby switch. In this way, the extraction unit is only working whilst the attached soldering station is in operation, stopping as soon as the soldering station goes into standby mode.
