Gebildet 2pcs Car Relay Harness 12V 40A 4 Pin SPST Harness Sockets with Color-Labeled Wires for Automotive Truck Motorcycle Boat
$0.00
- Brand new heavy duty SPST(Single Pole Single Throw)relays with color-labeled wires.
- Rated operational voltage:12V/Switching Capability:40A.
- Minimum operating voltage 8V,corresponding minimum operating current is 100mA;Standard operating voltage 12V,corresponding standard operating current is 150mA.
- Small size/Low power consumption/High contact voltage/High sensitivity.
- Contact Material:Ag Alloy/Contact Resistance:≤100MΩ.Life Expectancy Electrical:100,000 Operation,Life Expectancy Mechanical:10,000,000 Operation.
This product is fulfilled by seller
Package Included:
2×Car Relay Harness
8×Connect terminals
8×Rubber sleeve
Relay technical specification:
Relay load: 40A/12VDC
Contact Resistance: ≤ 100MΩ
Contact Material: Ag Alloy
Life Expectancy Electrical: 100,000 Operation
Life Expectancy Mechanical: 10,000,000 Operationss (at 300 Operations/min)
Coil power:1.8W
Operate Time: ≤15ms
Release Time: ≤10ms
Initial withstand voltage of Contact and Contact: 1000VAC/1min
Initial withstand voltage of Contact and Coil: 1500VAC/1min
Insulation Resistance: 100MΩ/( 500VDC)
Temperature Range: -55°C ~+70°C
Humidity Range:35%-80%
Atmospheric Pressure:86-106KPa
After Sale Service:
Customer satisfaction is our greatest pursuit, If you found our products don’t work or not so good quality as you think, Please contact us without hesitation. We can resend you a new item or 100% refund money as you like.
2×Car Relay Harness
8×Connect terminals
8×Rubber sleeve
Relay technical specification:
Relay load: 40A/12VDC
Contact Resistance: ≤ 100MΩ
Contact Material: Ag Alloy
Life Expectancy Electrical: 100,000 Operation
Life Expectancy Mechanical: 10,000,000 Operationss (at 300 Operations/min)
Coil power:1.8W
Operate Time: ≤15ms
Release Time: ≤10ms
Initial withstand voltage of Contact and Contact: 1000VAC/1min
Initial withstand voltage of Contact and Coil: 1500VAC/1min
Insulation Resistance: 100MΩ/( 500VDC)
Temperature Range: -55°C ~+70°C
Humidity Range:35%-80%
Atmospheric Pressure:86-106KPa
After Sale Service:
Customer satisfaction is our greatest pursuit, If you found our products don’t work or not so good quality as you think, Please contact us without hesitation. We can resend you a new item or 100% refund money as you like.
| Brand Name | Gebildet |
|---|---|
| Part Number | E456 |
| Wattage | 1.800000 |
| Wattage Unit | Watts |
| Current Rating Unit | Amps |
| Current Rating | 40.000000 |
| Upper Temperature Rating | 70.000000 |
| Maximum Switching Current Unit | Amps |
| Maximum Switching Current | 40.000000 |
| Coil Voltage | 12.000000 |
| Coil Voltage Unit | Volts |
| Contact Current Rating Unit | Amps |
| Contact Current Rating | 40.000000 |
| Minimum Switching Voltage | 8.000000 |
| Operating Time | 0.015000 |
| Operating Time Unit | Seconds |
