IDEAL Electrical 30-1333S In-Sure Push-In 3 Port Connector Orange, (10PK)
$5.00
- Push-in wire connector to join and insulate 3 wires
- No-twist design reduces repetitive motion fatigue
- Minimum capacity of three # 20 solid wires, Maximum capacity of three # 12 solid wires
- Stranded wire range: # 16 - # 12 AWG (19 strand) and # 18 AWG (7 strand), Tin bonded stranded wire range: # 18 - # 14 AWG (19 strand)
- Product specifications: Rated to 600-Volt maximum, clear shell gives visual verification of your connection, UL listed to 486C CSA certified to C22.2 #188, Tough, UL 94V-2 flame-retardant shell rated at 105 C (221 F)
This product is fulfilled by seller
| Brand Name | Ideal Industries |
|---|---|
| Part Number | 30-1333S |
| Voltage Unit | Volts |
| Gauge Decimal Value | 12.000000 |
| Gauge String Value | 12 |
| Maximum Voltage Unit | Volts |
| Maximum Voltage | 600.000000 |
| Operating Voltage Unit | Volts |
| Operating Voltage | 600.000000 |
| Item Height Unit | Inches |
| Item Height base to top | 0.770000 |
| Item Length Unit | Inches |
| Item Length Longer Edge | 0.690000 |
| Item Width Unit | Inches |
| Item Width Shorter Edge | 0.380000 |
