TPM-01E Energy Analyzer Multimeter 3P&4W (Color : 3CT 50A)

General
TPM-01E Energy analyzers measures load or voltage, current,cos, active power, reactive power, minimum and maximum values of the load.
Features
Easy Installation and Operation with 4×4 Digit
Display
With 3-Phase Voltage and 3-Phase Current
Transformers
Easy-To-Use Menu
It Shows Per-Phase Active Powers (P)
It Shows Per-Phase Total Reactive Powers (Q,
Q Inductive and Capacitive)
It Shows Per-Phase Apparent Powers (S)
It Shows Cos and Power Factor Values of
Each Phase
It Shows Voltage (V) and Current (I) Values of
Each Phase
It Shows Total Import and Export Active
Energy (kWh) Values
It Shows Total Inductive and Capacitive
Reactive Energy (kVArh) Values
It Shows the Minimum and Maximum Values
Can Reset the Energy Values
Password Protected Menu
Construction
1-Shows the unit of the value.
L-N: Phase-Neutral Voltage.
L-L: Phase-Phase Voltage.
A: Current.
Cos: Cosinus Fi and Power Factor.
W: Watt (Active Power). (If it is shown with"-",it is Export Active Power.).
Var: Reactive Power. (If it is shown with"-",it is Capacitive Power.).
VA: Apparent Power.
kWh: Active Energy.
kVArh: Reactive Energy. (If it is shown with"-",it is Capacitive Energy.).
Hz: Frequency.
2- Shows which phase the value belongs to.(L1,L2,L3)
3- Specifies the type of value shown.Minimum.maximum, average.
Min.: Indicates that the values shown are minimum.(Period: 2 seconds.)
Max.: Indicates that the values shown are maximum.(Period: 2 seconds.)
Average: Indicates that the values shown are minimum.(Period: 5 minutes.)
4- It shows the magnitude of the current value drawn from the system.
L: This LED will light if the current value in any phase is 1A or less.
M: This LED will light if the current value in any phase is between 1A and 4A.
H: This LED will light if the current value in any phase i
