100Pcs P50-J1/P50-B1/P75-B1 Spring Test Probe Round Pogo Pin Tools for PCB Testing
$20.01
- [Versatile Testing Capabilities] Cone shape head ideal for through-hole component testing.
- [Ideal Replacement Probes] Suitable for replacing broken or old test probes on your pcb.
- [Durable Set of 100pcs] Long-lasting spring test probes for continuous usage.
- [Wide Application] Great for testing pcb gold fingers, connectors, and pads.
- [Essential Parts for Pcb Testing] Spring test probes allow easy access to components on printed circuit assemblies.
This product is fulfilled by seller
Specification:
P75-E2:
head Shape: Cone
Current Rating: 3A
: 50mΩ
Stroke: 6.5mm
head Diameter: 1.5mm
Probe Tube Diameter: 1.36mm
Probe Rod Diameter: 0.99mm
Probe Length: 33.3mm
Boring Size: 1.7mm
Min. Test Interval: 2.54mm
Quantity: 100pcs
P50-J1:
head Shape: Round
Current Rating: 3A
: 50mΩ
Stroke: 2.6mm
Probe Tube Diameter: 0.68mm
Probe Rod Diameter: 0.48mm
Probe Length: 16mm
Boring Size: 0.9mm
Min. Test Interval: 1.27mm
Quantity: 100pcs
P100-E2:
head Shape: Cone
Current Rating: 3A
: 50mΩ
Stroke: 6.5mm
head Diameter: 1.5mm
Probe Tube Diameter: 1.36mm
Probe Rod Diameter: 0.99mm
Probe Length: 33.3mm
Boring Size: 1.7mm
Min. Test Interval: 2.54mm
Quantity: 100pcs
P50- B1 - 16mm
Pin Centre: 0.68mm
Min test distance: 1.27mm
Spring Pressure: 75g
Full Stroke: 2.65mm
Current Rating: 3A
Current : 50mm
Plunger: Heat Treated Copper
: Phosphor Bronze . Gold Plated
Spring: stainless steel
P75-B1:
Specification:spring thimble
Needle tube diameter: 1.02mm
Needle bar diameter:0.74mm
Pin Total Length: 15.8mm
Drill size: 1.4mm;
Minimum distance between test: 1.91mm
Package Included:
100 x Probes
P75-E2:
head Shape: Cone
Current Rating: 3A
: 50mΩ
Stroke: 6.5mm
head Diameter: 1.5mm
Probe Tube Diameter: 1.36mm
Probe Rod Diameter: 0.99mm
Probe Length: 33.3mm
Boring Size: 1.7mm
Min. Test Interval: 2.54mm
Quantity: 100pcs
P50-J1:
head Shape: Round
Current Rating: 3A
: 50mΩ
Stroke: 2.6mm
Probe Tube Diameter: 0.68mm
Probe Rod Diameter: 0.48mm
Probe Length: 16mm
Boring Size: 0.9mm
Min. Test Interval: 1.27mm
Quantity: 100pcs
P100-E2:
head Shape: Cone
Current Rating: 3A
: 50mΩ
Stroke: 6.5mm
head Diameter: 1.5mm
Probe Tube Diameter: 1.36mm
Probe Rod Diameter: 0.99mm
Probe Length: 33.3mm
Boring Size: 1.7mm
Min. Test Interval: 2.54mm
Quantity: 100pcs
P50- B1 - 16mm
Pin Centre: 0.68mm
Min test distance: 1.27mm
Spring Pressure: 75g
Full Stroke: 2.65mm
Current Rating: 3A
Current : 50mm
Plunger: Heat Treated Copper
: Phosphor Bronze . Gold Plated
Spring: stainless steel
P75-B1:
Specification:spring thimble
Needle tube diameter: 1.02mm
Needle bar diameter:0.74mm
Pin Total Length: 15.8mm
Drill size: 1.4mm;
Minimum distance between test: 1.91mm
Package Included:
100 x Probes
| Brand Name | Marhynchus |
|---|---|
| Part Number | Marhynchus0dxg3mfrk2 |
