PF10000558060
In stock
SDI to HDMI Converter, SDI in HDMI Out with SDI Loopout, 1080P@60Hz Audio Embedder Support HDMI 1.3, 3G/HD-SDI Auto Format Detection Extender for Camera CCTV
$0.00
- SDI to HDMI Converter: Convert pure digital SDI signals to HDMI signal. Auto format detection for 3G-SDI, HD-SDI and SD-SDI. NOTE: This is not a bi-directional converter. Can NOT be used for HDMI to SDI conversion.
- SDI in HDMI out and SDI Loopout: Support 1 HDMI output and 1 SDI Loop Output, SDI data transfer rate up to 2.97Gbps, HDMI Output up to 1080P@60Hz. The loop-through design also allows you to view the original SDI content on an SDI monitor simultaneous with the HDMI display.
- Resolutions: SDI input support 480i, 567i, 720P@30/50/60Hz, 1080i@ 50/60Hz, 1080p@24/25/30/50/60Hz. HDMI output support 720P@ 50/60Hz, 1080p@24/25/30/50/60Hz.
- Automatic Input Signal Detection:Support Auto detection of SD or HD,Supports 10-bit Deep Color,Work as SDI Repeater & Extender with the Re-clock function and support multiple cascaded (Note: It is best not to connect in series with other converters of the same type.)
- What You Get: SDI to HDMI Converter X 1, Power Adapter X 1, User Manual X 1.
This product is fulfilled by seller
SDI to HDMI Converter, SDI in HDMI Out with SDI Loopout, 1080P@60Hz Audio Embedder Support HDMI 1.3, 3G/HD-SDI Auto Format Detection Extender for Camera CCTV
SDI to HDMI Converter Designed for professional SMPTE video applications, this SDI to HDMI Converter allows SDI signals to be shown on HDMI displays to give you fast signal transmission without any loss. The loop-through design also allows you to view the original SDI content on an SDI monitor simultaneous with the HDMI display.
Specifications
- Input Port: 1 x BNC (SDI/HD-SDI/3G-SDI)
- Output Port: 1 x HDMI, 1 x SDI Output (BNC)
- Power Supply: USB DC 5V/1A
Features
- HDMI input compatible devices: TV, Monitor, Projector
- SDI data rates: 270Mb/s, 1.485 Gbps, 2.97Gbps
- SDI input resolutions: 480i, 567i, 720P@30/ 50/ 60Hz, 1080i@ 50/ 60Hz, 1080p@24/ 25/ 30/ 50/ 60Hz.
- HDMI Output resolutions: 720P@ 50/ 60Hz, 1080p@24/ 25/ 30/ 50/ 60Hz.
- Supports SMPTE 425M, SMPTE 424M, SMPTE 292M, SMPTE 259M-C
- One way SDI output, with the Re-clock function, can support multiple cascaded
Package
1 x SDI to HDMI Converter
1 x Power Adapter
1 x User Manual
NOTE
1. Only Support FHD up to 1080p,not support UHD 4K.
2. Only Support SDI signal,not support RF, CVBS, AHD, TVI, CVI.
3. This converter is SDI to HDMI Converter, can't be used reversed
SDI to HDMI Converter Designed for professional SMPTE video applications, this SDI to HDMI Converter allows SDI signals to be shown on HDMI displays to give you fast signal transmission without any loss. The loop-through design also allows you to view the original SDI content on an SDI monitor simultaneous with the HDMI display.
Specifications
- Input Port: 1 x BNC (SDI/HD-SDI/3G-SDI)
- Output Port: 1 x HDMI, 1 x SDI Output (BNC)
- Power Supply: USB DC 5V/1A
Features
- HDMI input compatible devices: TV, Monitor, Projector
- SDI data rates: 270Mb/s, 1.485 Gbps, 2.97Gbps
- SDI input resolutions: 480i, 567i, 720P@30/ 50/ 60Hz, 1080i@ 50/ 60Hz, 1080p@24/ 25/ 30/ 50/ 60Hz.
- HDMI Output resolutions: 720P@ 50/ 60Hz, 1080p@24/ 25/ 30/ 50/ 60Hz.
- Supports SMPTE 425M, SMPTE 424M, SMPTE 292M, SMPTE 259M-C
- One way SDI output, with the Re-clock function, can support multiple cascaded
Package
1 x SDI to HDMI Converter
1 x Power Adapter
1 x User Manual
NOTE
1. Only Support FHD up to 1080p,not support UHD 4K.
2. Only Support SDI signal,not support RF, CVBS, AHD, TVI, CVI.
3. This converter is SDI to HDMI Converter, can't be used reversed
| Brand Name | Anber-Tech |
|---|---|
| Part Number | SDI to HDMI Converter |
| Current Rating Unit | Amps |
| Current Rating | 1.000000 |
| Input Voltage Unit | Volts |
| Input Voltage | 5.000000 |
| Nominal Power Unit | Watts |
| Nominal Power | 5.000000 |
