MACHINIST X99 RS9 Server Motherboard LGA 2011-V3 Motherboard for Intel Xeon E5 V3/V4 and Core i7 5th/6th gen Series Processors, DDR4 Max 128GB, SATA 6Gbps, Gigabit LAN, NVME M.2, WiFi M.2, SATA 6Gbps
$109.99
- LGA 2011-3 Socket: The X99 motherboard supports Intel Xeon E5 V3/V4 series processors and Core i7 5th/6th gen processors. (Eg. E5-1660 V3, E5-2666 V3, E5-2650 V3, E5-2640 V3, E5-2680 V3, E5-1620 V4, E5-2686 V4, E5-2630 V4, E5-2650 V4, E5-2680 V4, i7-5960X, i7-6900K, etc.)
- 4-Channel DDR4 Slots: The Intel Micro ATX motherboard compatible with ECC, RECC and non-ECC DDR4 memory, the maximum capacity is 8*32GB. And supports 2133/2400MHz memory clock speed. (Server memory and desktop memory cannot be used together)
- High-speed M.2 Slots: This LGA2011-3 motherboard is equipped with two NVME M.2 (PCIe 3.0 X4 bandwidth) slots, maximum speed Up to 3600M/S
- PCIe Expansion Slots: The DDR4 gaming mainboard is equipped with 1 * PCIe 3.0 X16 slots and 2 * PCIe 2.0 X1 slots. Each lane can support a rate of 8Gbps, and the rate of the X16 slot can reach 128Gbps
- Other Powerful Components: 8-phase power supply, digital diagnostic card. And the placa madre with VRM cooling fan and heat dissipation armor protection for strong heat dissipation, to ensure stable bus communication
- Package Includes: 1*LGA 2011-v3 cooler bracket, 1*SATA cable, 1*I/O shield, 1*mainboard. User manual is not included in the package and can be downloaded from product description page "Product guides and documents" if you need
- Warm Tips: If no display, no boot, no screen, no network card, no sound card, etc., We can help you solve them. It is recommend driver download: Driver Talent, or use Win 10 system, it can help you solve all the driver problems
This product is fulfilled by seller
MACHINIST X99 RS9 Motherboard for Intel Core i7 5th/6th and XEON E5 V3/V4 series CPUs on LGA 2011-3 Socket, PC Server Computer Motherbaord
Common Problems:
1. The diagnostic card appears on the “FF” code, may be the CPU is incompatible, CPU pins on the foreign body or power supply is not properly connected. You can use an eraser to wipe the metal contact surface of the CPU to ensure cleanliness.
2. If the code “B7”, “B9”, “53”, “B0”, this is the motherboard did not Detect the memory problem. You can unplug the memory several times or use an eraser to wipe the metal contact surface of the memory to solve the problem.
3. The installation of Win 10 system can avoid a lot of unnecessary trouble, without having to download any drivers on their own to use the computer normally.
4. If you want to enter the BIOS, please press the “Del” key continuously after pressing the boot button. Please don't wait until the boot logo screen appears on the computer screen, because it's already too late.
X99 RS9 Motherboard Specification:
Main chipset: Intel B85/Q87
Motherboard structure: Micro ATX
CPU socket: Intel LGA 2011-3 (Support Intel Core i7 5th/6th , XEON E5 V3/V4)
Memory slot: DDR4 (Support 2400/2133 MHz, ECC, RECC and Non-ECC)
Maximum memory: 128GB
PCIe slot: 1 * PCIe 3.0 X16 slots, 2 * PCIe 2.0 X1 slots.
Storage interface: 6 * SATA 3.0, 2 * NVME M.2
USB Port: Rear(2 * USB 3.0, 6 * USB 2.0), Front(1 * USB 3.0, 1 * USB 2.0)
Onboard LAN: 1 * Gigabit LAN Port, 1 * WIFI M.2 Slot
Power connector: 24pin + 8pin DC
Power Supply: 8-layer PCB
Motherboard size: 235mm x 200mm
Package list:
1 * motherboard
1 * SATA cable
1 * LGA2011-3 cooler bracket
1 * I/O shield
Common Problems:
1. The diagnostic card appears on the “FF” code, may be the CPU is incompatible, CPU pins on the foreign body or power supply is not properly connected. You can use an eraser to wipe the metal contact surface of the CPU to ensure cleanliness.
2. If the code “B7”, “B9”, “53”, “B0”, this is the motherboard did not Detect the memory problem. You can unplug the memory several times or use an eraser to wipe the metal contact surface of the memory to solve the problem.
3. The installation of Win 10 system can avoid a lot of unnecessary trouble, without having to download any drivers on their own to use the computer normally.
4. If you want to enter the BIOS, please press the “Del” key continuously after pressing the boot button. Please don't wait until the boot logo screen appears on the computer screen, because it's already too late.
X99 RS9 Motherboard Specification:
Main chipset: Intel B85/Q87
Motherboard structure: Micro ATX
CPU socket: Intel LGA 2011-3 (Support Intel Core i7 5th/6th , XEON E5 V3/V4)
Memory slot: DDR4 (Support 2400/2133 MHz, ECC, RECC and Non-ECC)
Maximum memory: 128GB
PCIe slot: 1 * PCIe 3.0 X16 slots, 2 * PCIe 2.0 X1 slots.
Storage interface: 6 * SATA 3.0, 2 * NVME M.2
USB Port: Rear(2 * USB 3.0, 6 * USB 2.0), Front(1 * USB 3.0, 1 * USB 2.0)
Onboard LAN: 1 * Gigabit LAN Port, 1 * WIFI M.2 Slot
Power connector: 24pin + 8pin DC
Power Supply: 8-layer PCB
Motherboard size: 235mm x 200mm
Package list:
1 * motherboard
1 * SATA cable
1 * LGA2011-3 cooler bracket
1 * I/O shield
| Brand Name | MACHINIST |
|---|---|
| Part Number | 00001 |
| Platform | Windows |
| Compatible Processors | LGA 2011-3 Socket CPUs |
| Memory Storage Capacity Unit | GB |
| Memory Storage Capacity | 128.000000 |
| Memory Clock Speed | 2400.000000 |
| Memory Clock Speed Unit | MHz |
| RAM Memory Maximum Size Unit | GB |
| RAM Memory Maximum Size | 128.000000 |
| Total PCIe Ports | 3 |
