LEONLITE 12 Pack One Gang Old Work Electrical Outlet Box, Standard 14 Cubic Inch Device Box, PVC Electrical Junction Box for Switch, Step Light, Outlet Box for Home Improvement, ETL Listed, Gray
$34.99
- For Old Work Applications: The electrical box is an ideal choice for home improvement and retrofit, equipped with four built-in wire holes to meet different wiring needs, allowing you to customize your home renovation
- Standard 14 CU.IN: The 14 cubic inches internal space can accommodate standard outlets, switches without requiring extensive wall damage. Additionally, the built-in cable clamp securely fastens the wires
- Compliance Certification: ETL Listed. Designed and listed for use with non-metallic sheathed cable in accordance with Article 314 of the National Electrical Code
- Safe To Use: The device box utilizes an ultra-thick PVC material that enhances stability and rigidity, providing exceptional rust resistance and durability. With its non-conductive properties, it guarantees a safe user experience
- Product Dimensions: 4-5/16-Inch Length; 2-1/4-Inch Width; 2-7/8-Inch Depth. Ideal for standard devices and switches with 3-1/4” screws spaced
This product is fulfilled by seller
This electrical box is specifically designed for old work. It is embedded into pre-cut gypsum boards according
to the hole dimensions, and the clamps on both sides automatically pop out to secure it.
The installation process is very simple and does not require extensive wall damage.
The device box is designed with an integrated construction, ensuring that no parts are lost or damaged. It is made of ultra-thick PVC material, guaranteeing stability, rust resistance, durability, and non-conductivity.
Specification
Listed：ETL
Material: PVC
Inner Volume: 14 CU.IN
Flame Rating: 2 HOUR WALL
Compatible With Screws: # 6-32
Maximum Allowed Number Of Wires (PCS/AWG): 7/14, 6/12, 5/10
Cutout Hole Size: 3.76*2.29 Inches
| Brand Name | LEONLITE |
|---|---|
| Part Number | A-49391 |
| Capacity | 14.000000 |
| Item Depth Unit | Inches |
| Item Depth Front to Back | 2.800000 |
| Item Height Unit | Inches |
| Height Top to Bottom | 2.812500 |
| Item Width Unit | Inches |
| Item Width Side to Side | 2.250000 |
