Molence IDC64 2x32 Pins 0.1" Male Header Breakout Board, 64-Pin Dual-Row IDC Connector C45 DIN Rail Mounting Terminal Block Adapter for PLC CNC MCU
$26.99
- 64 Pins (2 x 32) 0.1" Pitch: This IDC64 breakout board brings all 64 pins of its male dual row header out to screw terminal blocks. Each pin is also brought to solder pads (3 per pin) at 0.1" (2.54mm) spacing, allowing the easy addition of pin headers.
- DIN Rail Mounting: DIN come with DIN clips already installed and ready to snap onto 35mm or 32mm DIN rail. Screw terminals accomodate wire sizes from 12AWG to 22AWG.
- The IDC64-Pin Adapter Terminal Board bridges the gap between ribbon cables and screw-terminal devices, offering a reliable interface for industrial automation, CNC machine wiring, and custom electronics projects.
- Quick Connection: Ejector latches on header provide secure connection and quick disconnection.
- Widely Applications: It is well-suited for interfacing with I/O cards, data acquisition (DAQ)
This product is fulfilled by seller
A dual row header is sometimes referred to as an "IDC Header", "IDC connector", or "ribbon cable connector". A breakout board is sometimes referred to as a "transition module", "terminal board", "terminal block", "breakout box", "breakout adapter", "terminator", or "interface module".
Specifications:
Pin pitch: Dual row 0.1"/2.54mm spaced male pin header
Terminal Pitch: 0.2”/5.08mm
Rated voltage: 60V
Rated current: 1A/per pin
Wire range: 22-12AWG
Strip length: 5mm
Screws: M3,steel,Zinc plating color
Pin header and Cage: Gilded(3U)
FR-4 fiber glass PCB
Dual copper layers
Operating Temperature: -20ºC to 50ºC
DIN rail mountable: 15/32/35mm
PCB Dimensions: 183mm x 87mm x 53mm/7.20" x 3.43" x 2.09"(L x W x H)
Package Content:
1PCS IDC64 2x32 Pins 0.1" Male Header Breakout Board
Specifications:
Pin pitch: Dual row 0.1"/2.54mm spaced male pin header
Terminal Pitch: 0.2”/5.08mm
Rated voltage: 60V
Rated current: 1A/per pin
Wire range: 22-12AWG
Strip length: 5mm
Screws: M3,steel,Zinc plating color
Pin header and Cage: Gilded(3U)
FR-4 fiber glass PCB
Dual copper layers
Operating Temperature: -20ºC to 50ºC
DIN rail mountable: 15/32/35mm
PCB Dimensions: 183mm x 87mm x 53mm/7.20" x 3.43" x 2.09"(L x W x H)
Package Content:
1PCS IDC64 2x32 Pins 0.1" Male Header Breakout Board
| Brand Name | Molence |
|---|---|
| Part Number | IDC-64M-A3 |
| Lower Temperature Rating | -20.000000 |
| Gauge Decimal Value | -0.010000 |
| Operating Voltage Unit | Volts |
| Operating Voltage | 60.000000 |
