PF10000544413
In stock
FM Transmitter 1000W+Antenna+30M Cable, Long Range Touch Screen FM Radio Broadcast Transmitter for Church and Radio Station
$2,760.00
- 【Overheat protection】The transmitter will switch to auto-protection with alarm message and a beep sound once the working temperature gets higher than normal range.
- 【Over SWR protection】SWR is the indication of antenna system connection with transmitter. Once the connection is bad and causing a high SWR Value, the transmitter will switch to automatic protection mode by showing alarm message on the screen with a beeping sound meanwhile.
- 【FAN error alarm】When the fan stops running, the alarm message will be displayed on the screen.
- 【Low Noise Performance】 High-quality FM transmitters maintain a low noise floor to ensure that the audio remains clear and free from unwanted interference or hiss
- 【Long range fm transmitter】Long Range higher power ensures a larger coverage area and stronger signal reception. 1000W FM Transmitter can coverage radius 20-25KM.
- 【Touch screen fm transmitter】Touch screen easily and faster setting, all by one touch
This product is fulfilled by seller
Product Description
1. Frequency Range:88.1MHz~107.9 MHz
2. Frequency Setting step:10KHz
3. Carrier Frequency precision:±200Hz
4. Residual Wave Radiation:≥65dBc
5. Audio Input Impedance:600Ω,Balance
6. Separation:60dB Pilot Signal Modulation:8%~10%
7. Audio Input Level:±10dBm,step 0.01dB
8. S/N:≥75dB(30H~15kHz,100%)
9. Audio Harmonic Distortion:<0.05%
10. Audio response: ±0.05dB(30Hz~15KHz)
11. Output Load Impedance:50Ω
12. Output Power:0-1000W
13. Pre-emphasis:0μS,50μS,75μS
14. Deviation:±75kHz
15. Pilot Frequency: 19 kHz±1Hz
16. Sub-carrier Suppression:≥65dB
17.RF Output Connector:7/16'(female)or7/8'Flange
18.Size:460mm*480mm*88mm
19.Weight: 15KG
Product Features
The DSP(Digital Sound Processing) technology makes the YXHT- 1000W FM transmitter an enjoyable sound broadcasting device for all music lovers, you’ll no longer be bothered by the noises or distortions. As quality assurance, YXHT Provides 6 YEAR warranty for this professional broadcast transmitter, you’ll have no worries to use it for the radio station.
Application
FREQUENTLY APPLICABLE USES:
1). Community Radio stations
2). LPFM radio stations
3). City radio stations
4). Christian Church radio stations
Package include
Transmitter, 1-bay antenna, 30M cable, audio line, power line
1. Frequency Range:88.1MHz~107.9 MHz
2. Frequency Setting step:10KHz
3. Carrier Frequency precision:±200Hz
4. Residual Wave Radiation:≥65dBc
5. Audio Input Impedance:600Ω,Balance
6. Separation:60dB Pilot Signal Modulation:8%~10%
7. Audio Input Level:±10dBm,step 0.01dB
8. S/N:≥75dB(30H~15kHz,100%)
9. Audio Harmonic Distortion:<0.05%
10. Audio response: ±0.05dB(30Hz~15KHz)
11. Output Load Impedance:50Ω
12. Output Power:0-1000W
13. Pre-emphasis:0μS,50μS,75μS
14. Deviation:±75kHz
15. Pilot Frequency: 19 kHz±1Hz
16. Sub-carrier Suppression:≥65dB
17.RF Output Connector:7/16'(female)or7/8'Flange
18.Size:460mm*480mm*88mm
19.Weight: 15KG
Product Features
The DSP(Digital Sound Processing) technology makes the YXHT- 1000W FM transmitter an enjoyable sound broadcasting device for all music lovers, you’ll no longer be bothered by the noises or distortions. As quality assurance, YXHT Provides 6 YEAR warranty for this professional broadcast transmitter, you’ll have no worries to use it for the radio station.
Application
FREQUENTLY APPLICABLE USES:
1). Community Radio stations
2). LPFM radio stations
3). City radio stations
4). Christian Church radio stations
Package include
Transmitter, 1-bay antenna, 30M cable, audio line, power line
| Brand Name | HKSUZNAGHL |
|---|---|
| Part Number | 00001 |
| FCC ID | 2A8OX-RSF-300W |
