PF10000544141
In stock
GaiRen 1 1/4'' Heim Joints Rod End Kit, 1.25'' Pair of Right and Left Hand Thread Chromoly Joints Heat Treated Chromoly with Round Tube Adapter, High Misalignment Spacer
$109.99
- 【Rod End Heim Joint Kit】2 right hand thread and 2 Left hand thread Heim set along with jam nut spacers that are zinc coated to offer more durability and tube adapter.
- 【Max Load Capacity】The panhard rod end kits are heat treated and hard chrome plated to provide a longer use. 28,000 Pound static load rating for heavy-duty performance.
- 【Adaptability】Equipped with a 1 1/4” shaft with 12 tpi and a 1” bore, ensuring maximum strength. Compatible with tube sizes: 1 3/4" OD x 0.120" Wall x 1.5" ID, with a mounting width of 2-5/8"
- 【Widely Use】The 3/4 rod ends heim joint kit is great for steering and suspension ,traction bars, traction bar kit, panhard bar, steering joints, johnny joint, tie rod, and links joints on hot rods.
- 【Customer Service】Any questions about our Heim Joints Rod End Kt. Please feel free to contact us. We will reply to you as soon as possible within 24 hours.
This product is fulfilled by seller
3/4” Adjustable Rod End Heim Joint Kit
Rod End
Thread Size:3/4"-16
Ball Bore: 0.750"
Ball Width: 0.875"
Centerline Length: 2.875"
Thread Length: 1.750"
Load rating capacity: 28,081 lbs
3/4 Bung
Thread Size: 3/4"-16
Fits Tube Size: 1 1/4" OD.x .120" Wall x 1.01"ID.
High Misalignment Spacer
Thread Size:3/4"-5/8"
Jam Nut
Thread:3/4"-16
Width: 1.125"
Height: 0.446"
Carbon Steel, Silver Zinc Plated
Package List
2 Set of Heim Joints Rod End Kt (2 right hand & 2 left hand)
| Brand Name | GaiRen |
|---|---|
| Part Number | 77452701339 |
