YFYIQI 45°/0 Spectrophotometer Grating Spectrophotometer Color Spectrophotometer with Capacitive Touch Screen Integrating Sphere Size 48mm Data Memory Standard 500 Sample 20000

PRODUCT FEATURES:
☀Integrating Sphere Size:Φ48mm
☀Light Source:Combined LED Light
☀Spectral separation device:Concave Grating
☀Detector:256 Image Element Double Array CMOS Image Sensor
☀Wavelength Range:400~700nm
☀Wavelength Pitch:10nm
☀Half Bandwidth:10nm
☀Reflectance Range:0~200%
☀Measuring Aperture:Customized One Aperture：MAV:Φ8mm/Φ10mm；SAV:Φ4mm/Φ5mm；SAV:Φ2mm/Φ3mm；
☀Color Space:CIE LAB,XYZ,Yxy,LCh,CIE LUV,HunterLAB,βxy
☀Color Difference Formula:ΔE*ab,ΔE*uv,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*00,ΔE（Hunter）
☀Observer Angle:2°/10°
☀Illuminant:D65,A,C,D50,D55,D75,F1,F2(CWF),F3,F4，F5，F6,F7(DLF),F8,F9，F10(TPL5),F11(TL84),F12(TL83/U30)
☀Display Data:Spectrogram/Values, Chromaticity Values, Color Difference Values/Graph, Pass/Fail Result, Color Offset
☀Measurement Time:About 1.5s
☀Repeatability:Spectral reflectance:
MAV,Standard deviation within 0.1% (400 nm to 700 nm: within 0.2%)
Chromaticity value:MAV,within ΔE*ab 0.05( When a white calibration plate is measured 30 times at 5 second intervals after white calibration)
☀Inter-instrument Error:Within ΔE*ab 0.2 (Average for 12 BCRA Series II color tiles)
☀Measurement mode:Single Measurement, Average Measurement(2-99)
☀Size(L*W*H):184*77*105mm
☀Weight:About 600g
☀Power source:Li-ion battery. 5000 measurements within 8 hours
☀Illuminant Life Span:5 years, more than 3 million times measurements
☀Display:3.5-inch TFT color LCD, Capacitive Touch Screen
☀Interface:USB
☀Data memory:Standard 500 Pcs, Sample 20000 Pcs
☀Language:Chinese,English
☀Storage Environment:Temperature: -20~50℃; Humidity: 0~85% (No Condensation)
☀Standard Accessory:Power Adapter, USB Cable, Built-in li-ion battery, User Manual, software(download from the website)White and Black Calibration Board, Protective Cover.
☀Optional Accessory:Micro Printer, Powder Test Box, Universal test components, Locating Plate
