PF10000539431
In stock
XIASABA USB20 HDMI Video Capture Card 1 Way Live Broadcast Recording Box Support for OBS Enables Simultaneous Capture of HDMI Video and Audio Transmits Signals to Computer Or Smar
$21.59
- Video And Audio Capture: The USB
- 2.0 capture card is a remarkable device that can capture HDMI video and HDMI audio at the same time. This feature allows users to get a complete media experience. It transmits both audio and video signals to a computer or smartphone which enables users to preview and store the content. It is suitable for various scenarios like high definition acquisition teaching recording and video projects making it a versatile tool for many users Resolution And Color Support: This capture card offers excelle
- Cable And Transmission: The capture card supports the use of a standard AWG26 cable. This cable allows an input transmission distance of up to 15 meters for resolutions of 1080P and below. This long distance transmission capability gives users more flexibility in setting up their recording or broadcasting equipment without being restricted by short cable lengths
- Software And System Compatibility: It is highly compatible with various software and systems. This capture card supports most capture software such as VLC OBS and Amcap. Also it is compatible with Windows Android and OS X operating systems. This wide range of compatibility makes it easy for different users to integrate the device into their existing setups
- Portability And Standards Compliance: One of the great advantages of this capture card is its portability. It doesn't require an external power supply and has a compact size which makes it easy to carry around. Moreover it conforms with USB Video and UVC standards as well as USB Audio UAC standard ensuring Quality performance and reliable operation
This product is fulfilled by seller
BE Condition: brand new
Item type: HDMI Video Capture
Material: metal
Color: black
Weight: Approx. 52g
Size: Approx. 64x28x16mm/2.5x1.1x0.6in
HDMI resolution: the highest input can support 4K
Video input format: 8/10/12-bit color depth
Video output mode: YUV, JPEG
Video output resolution: Maximum output resolution 1080P
Support audio format: L-PCM
Input cable length: 15 meters, AWG26 HDMI standard cable
Maximum working current: 0.4A/5VDC
Operating temperature range: -10 ~ +55℃
Connection operation:
1. Connect the UHD signal source and the HDMI input port of the USB capture card through 1 HDMI cable.
2. Plug the USB male of the USB capture card into the USB port of the computer.
3. Capture operation steps (OBS): Open the software add a new source select ‘video capture device’ set the screen size select ‘studio mode’ (dual window) click ‘start recording’.
See specific examples:
(1). Add a new source and select ‘Video Capture Device’.
(2). Set the screen size
(3). Select ‘studio mode’ (dual window) and the above settings are completed.
Package List:
1 x
HDMI Video Capture1 x Instruction
Note:
Computer hardware configuration requirements
CPU: PC for i5‑3400 or above; for NB i7‑3537U 2.0GHZ or above
Graphics card: PC for NVIDIA GT630 or above; NC for NVIDIA GT735M or above
Storage: 4G for RAM
AF
Item type: HDMI Video Capture
Material: metal
Color: black
Weight: Approx. 52g
Size: Approx. 64x28x16mm/2.5x1.1x0.6in
HDMI resolution: the highest input can support 4K
Video input format: 8/10/12-bit color depth
Video output mode: YUV, JPEG
Video output resolution: Maximum output resolution 1080P
Support audio format: L-PCM
Input cable length: 15 meters, AWG26 HDMI standard cable
Maximum working current: 0.4A/5VDC
Operating temperature range: -10 ~ +55℃
Connection operation:
1. Connect the UHD signal source and the HDMI input port of the USB capture card through 1 HDMI cable.
2. Plug the USB male of the USB capture card into the USB port of the computer.
3. Capture operation steps (OBS): Open the software add a new source select ‘video capture device’ set the screen size select ‘studio mode’ (dual window) click ‘start recording’.
See specific examples:
(1). Add a new source and select ‘Video Capture Device’.
(2). Set the screen size
(3). Select ‘studio mode’ (dual window) and the above settings are completed.
Package List:
1 x
HDMI Video Capture1 x Instruction
Note:
Computer hardware configuration requirements
CPU: PC for i5‑3400 or above; for NB i7‑3537U 2.0GHZ or above
Graphics card: PC for NVIDIA GT630 or above; NC for NVIDIA GT735M or above
Storage: 4G for RAM
AF
| Brand Name | XIASABA |
|---|---|
| Part Number | XIASABAkynx8csua2 |
| Includes Remote? | No |
