plysbmlygj Industrial Ultra-Thin Jack, not Used in Cars (30T Hydraulic Jack + CP-700 Pump)
$162.99
- Easy to Operate: You just need to press the handle up and down to jack up heavier items, so it is very labor-saving and convenient to use.
- Large Tonnage: It has a tonnage of 30T/66138lbs, which is suitable for shipyards, bridges, large machines.
- Good Materials: This product is made of high-quality steel and rubber, which is strong, durable, and not easy to deform. Good materials can extend its service life.
- Easy to Carry: The product is a split type, you can detach the jack and pump to convenience you to carry.
- Quick Coupling: The quick coupling adopts threaded ZG3/8, which is equipped with a steel ball to prevent oil leakage, making it safer to use.
This product is fulfilled by seller
Description
This hydraulic jack is made of high-quality steel and rubber, which is strong, durable, and not easy to deform. It has a tonnage of 30T/66138lbs, which is large enough to meet your work needs.
Details
Stop Ring: The stop ring can play a protective role for the jack to prevent breakage and damage when it is under load, making it safer to use.
Plastic Spraying Treatment: The housing of the jack is treated with plastic spraying, so it is not easy to lose paint and rust, which can prolong the service life of this product.
Application
It is often used in power, chemical, steel, bridges, and other industries. It is suitable for railway vehicle maintenance, mechanical installation, construction engineering support, etc.
Specification
Color: Black, Yellow, Silver
Material: Steel
Quick Coupling Type (Thread): ZG3/8
Fuel Hose Material: Rubber
Jack Model: RSC-3050
Tonnage: 30T/66138lbs
Travel(Adjustable Height): 50mm/1.9inch
Jack Height: 105mm/4.1inch
Jack Extended Height: 155mm/6.1inch
Jack Diameter: 104mm/4.09inch
Oil Storage Capacity: 210CC
Jack Weight: 5.5kg/12.1lbs
Pump Model: CP-700
Oil Storage Capacity: 700CC
Pump Max. Pressure: 70MPa
Pump Min. Pressure: 7MPa
Pump Weight: 10.5kg/23.1lbs
How to Use
1. First, connect the quick connector of the manual pump to the jack.
2. Select the position and tighten the hydraulic pump drain screw clockwise.
Notes
1. Please keep the load bearing surface hard and flat and do not exceed the tonnage and rated strok, otherwise, the cylinder will be damaged.
Package Including
1* Hydraulic Jack
1* Pump
This hydraulic jack is made of high-quality steel and rubber, which is strong, durable, and not easy to deform. It has a tonnage of 30T/66138lbs, which is large enough to meet your work needs.
Details
Stop Ring: The stop ring can play a protective role for the jack to prevent breakage and damage when it is under load, making it safer to use.
Plastic Spraying Treatment: The housing of the jack is treated with plastic spraying, so it is not easy to lose paint and rust, which can prolong the service life of this product.
Application
It is often used in power, chemical, steel, bridges, and other industries. It is suitable for railway vehicle maintenance, mechanical installation, construction engineering support, etc.
Specification
Color: Black, Yellow, Silver
Material: Steel
Quick Coupling Type (Thread): ZG3/8
Fuel Hose Material: Rubber
Jack Model: RSC-3050
Tonnage: 30T/66138lbs
Travel(Adjustable Height): 50mm/1.9inch
Jack Height: 105mm/4.1inch
Jack Extended Height: 155mm/6.1inch
Jack Diameter: 104mm/4.09inch
Oil Storage Capacity: 210CC
Jack Weight: 5.5kg/12.1lbs
Pump Model: CP-700
Oil Storage Capacity: 700CC
Pump Max. Pressure: 70MPa
Pump Min. Pressure: 7MPa
Pump Weight: 10.5kg/23.1lbs
How to Use
1. First, connect the quick connector of the manual pump to the jack.
2. Select the position and tighten the hydraulic pump drain screw clockwise.
Notes
1. Please keep the load bearing surface hard and flat and do not exceed the tonnage and rated strok, otherwise, the cylinder will be damaged.
Package Including
1* Hydraulic Jack
1* Pump
| Brand Name | plysbmlygj |
|---|---|
| Part Number | 41710287C7LC |
