Gebildet 12V Fuse Relay Switch Harness Set - 30A ATO/ATC Blade Fuse, 5-Pin SPDT Automotive Electrical Relays with Heavy Duty 12 AWG Wires (Pack of 3)
$0.00
- Wiring - The relay sockets come with color-labeled wires for loads/accessories convenient wiring. Black - Ground (85), Red - VDC (30), White - Trigger (86), Blue - Output N/O (87),Green-87a Output Closed Contact.
- Neat Mounting Design - The interlocking design of unique male-female slot on each socket edge, easy to connect all relays together, offering clean and neat installation.
- Upgraded Version - Automotive relays built in fuse socket with included 30A blade fuse, no need of a separate fuse holder, saving space and money. Heavy duty 12AWG wires for main contact.
- Good Construction - 12V DC (Max14V DC) and 30A High Switching Capability. Bosch style 5-Pin SPDT (Single Pole Double Throw) Relay. Metal mounting bracket on the electrical relay promotes easy installation.
- Wide Application - Wide range of use, greatly used for car lights, fog lamps, wiper, starter, fans, speakers, traction control systems, etc.
This product is fulfilled by seller
Interchangeable/Compatible with:
All automobiles and devices equipped with a 12 Volt DC power source.
Product Features:
Built-in fuse socket with 30A blade fuse.
Bosch style 5-Pin SPDT (Single Pole Double Throw) Relay.
30A High Switching Capability.
Wire Specifications: Black - Ground (85), Red - VDC (30), White - Trigger (86), Blue - Output N/O (87). Yellow-87a Output Closed Contact
The built-in fuse holder on the automotive relay eliminates the need of a separate fuse holder in-line of the circuit, saving both space and money.
In addition to the build-in fuse, the purchase of this relay includes the relay harness, which features an interlocking function for ease of grouping multiple relays together.
Metal mounting tab on the electrical relay promotes easy installation.
All automobiles and devices equipped with a 12 Volt DC power source.
Product Features:
Built-in fuse socket with 30A blade fuse.
Bosch style 5-Pin SPDT (Single Pole Double Throw) Relay.
30A High Switching Capability.
Wire Specifications: Black - Ground (85), Red - VDC (30), White - Trigger (86), Blue - Output N/O (87). Yellow-87a Output Closed Contact
The built-in fuse holder on the automotive relay eliminates the need of a separate fuse holder in-line of the circuit, saving both space and money.
In addition to the build-in fuse, the purchase of this relay includes the relay harness, which features an interlocking function for ease of grouping multiple relays together.
Metal mounting tab on the electrical relay promotes easy installation.
| Brand Name | Gebildet |
|---|---|
| Part Number | E263 |
| Wattage | 360.000000 |
| Wattage Unit | Watts |
| Current Rating Unit | Amps |
| Current Rating | 30.000000 |
| Maximum Switching Current Unit | Amps |
| Maximum Switching Current | 30.000000 |
| Coil Voltage | 12.000000 |
| Coil Voltage Unit | Volts |
| Contact Current Rating Unit | Amps |
| Contact Current Rating | 30.000000 |
