4 - Pieces New HD44780 1602 LCD Display Modules, DC 5V, 16x2 Character, with Blue Backlight
$25.00
- The HD44780 1602 LCD Display Module operates on DC 5V and features a blue backlight for clear visibility.
- This 1602 LCD Display Module is capable of displaying 2 lines with 16 characters per line, suitable for various text - displaying needs.
- It has a commonly - used HD44780 controller built - in, ensuring stable and reliable performance for the 1602 LCD module.
- The 1602 LCD Display Module offers a practical solution for presenting information with its specific display capacity.
- The viewing area of this module measures 64.5mm x 16mm, providing a decent space for content viewing.
This product is fulfilled by seller
Data
The 1602 has a standard 16 - pin interface, details are as follows:
Pin 1 (VSS): It serves as the ground power.
Pin 2 (VDD): Connect to a 5V positive power supply.
Pin 3 (V0): It is the LCD contrast adjustment terminal. When connected to the positive power supply, the contrast is the weakest; when grounded, the contrast is the highest. Excessive contrast may cause "ghosting". Use a 10K potentiometer to adjust the contrast during operation.
Pin 4 (RS): It is for register selection. A high - level signal selects the data register, while a low - level signal selects the instruction register.
Pin 5 (R/W): It functions as the read/write signal line. A high - level signal indicates a read operation, and a low - level signal indicates a write operation.
Pin 6 (E): It is the enable terminal. When the E terminal transitions from high level to low level, the LCD module executes the command.
Pins 7 - 14 (D0 - D7): They are 8 - bit bidirectional data lines.
Pin 15: Connect to the positive power supply for the backlight.
Pin 16: Connect to the negative power supply for the backlight.
| Brand Name | hiBCTR |
|---|---|
| Part Number | H1-HBB0123-4 |
| Is the item dishwasher safe? | No |
