uxcell Flanged Sleeve Bearings 35mm Bore x 39.5mm OD x 15mm Length x 48mm Flange Dia x 2mm Flange Thickness Wrapped Oilless Bushings 2pcs
$10.39
- Size - Bore Diameter: 35mm; Outside Diameter: 39.5mm; Total Length: 15mm; Flange Diameter: 48mm; Flange Thickness: 2mm
- Material - Carbon steel base with Bronze Sintered and composite coating.
- Feature - Oilless, maintenance-free, good frictional property. Featured with good load capacity and wear resistance performance.
- Function - The bushings can be used for different purposes, such as positioning, wear and vibration reduction, or to isolate the shaft from special media to increase the life of the shaft.
- Application - Wide applications such as textile machines, printing machines, hydraulic loaders, fitness equipment and agricultural machinery.
This product is fulfilled by seller
Specification:
Material: Steel backing, Sintered Porous Spherical Copper Powder Layer, PTFE
Finish: Copper Plating
Friction Factor (Dry Friction): 0.04-0.2
Friction Factor (Oil Lubrication): 0.02-0.07
Bore Diameter: 35mm
Outside Diameter: 39.5mm
Length: 15mm
Flange Diameter: 48mm
Flange Thickness: 2mm
Package Contents:
2 x Sleeve Bearings
Description:
Plain Bearings are constructed with steel as a base, sintered porous spherical copper powder layer, copper-plated on the outer surface.
Wrapped Bushing is self-lubricating. It offers good frictional property, wear resistance and low noise.
Solid friction Oilless Bushing can operate during a wide temperature range. Suitable for applications with sliding movements.
Oilless Sleeve Bearings are most suitable for places where the self-lubricating properties of the material are required.
Note: Spilt Line can not be used for bearing.
Material: Steel backing, Sintered Porous Spherical Copper Powder Layer, PTFE
Finish: Copper Plating
Friction Factor (Dry Friction): 0.04-0.2
Friction Factor (Oil Lubrication): 0.02-0.07
Bore Diameter: 35mm
Outside Diameter: 39.5mm
Length: 15mm
Flange Diameter: 48mm
Flange Thickness: 2mm
Package Contents:
2 x Sleeve Bearings
Description:
Plain Bearings are constructed with steel as a base, sintered porous spherical copper powder layer, copper-plated on the outer surface.
Wrapped Bushing is self-lubricating. It offers good frictional property, wear resistance and low noise.
Solid friction Oilless Bushing can operate during a wide temperature range. Suitable for applications with sliding movements.
Oilless Sleeve Bearings are most suitable for places where the self-lubricating properties of the material are required.
Note: Spilt Line can not be used for bearing.
| Brand Name | uxcell |
|---|---|
| Part Number | a21121000ux0200 |
| California Proposition 65 Warning Type | Chemical |
