SFF-8644 to QSFP (SFF-8436) DDR Hybrid Mini SAS Cable, External Copper SAS Cable for NetApp DS4243 DS4246 DS2246, 100-Ohm, 2-Meter(6.6-ft)
- SFF-8644 to QSFP Cable, QSFP compatible for Cisco.
- Impedance = 100 Ohms
- Up to 10 Gbps transfer rate per channel.
- Precision process control for minimization of pair-to-pair skew.
- Fully compliant to the latest QSFP MSA (Multi-Source-Agreement) and the latest SAS3.0.
10Gtek's External Mini-SAS HD to QSFP+ cables maximize speed and port density for adapter cards, servers, and switches. This Mini SAS HD cable is guaranteed to perform at data-rates of 10.0 Gbps per lane, and features a pull-tab on both ends of SFF-8644 and QSFP+ connectors. Specifications:
Fully compliant to the latest QSFP MSA (Multi-Source-Agreement)
Fully compliant to the latest SAS3.0
Supports all current 40-Gigabit Ethernet standards
Up to 10 Gbps transfer rate per channel
30 AWG
Impedance = 100 Ohms
Single 3.3V power supply, low power consumption, <0.5W
Operating case temperature: -20 to 85°C
All-metal housing for superior EMI performance
Precision process control for minimization of pair-to-pair skew
AC coupling of PECL signals
EEPROM for cable signature & system communications
Low cross-talk and pair-to-pair skew maintains signal integrity
Fully RoHS compliant for environmental protection.
Applications
Fibre Channel
40G Ethernet
Infiniband
SAS 3.0
| Brand Name | 10Gtek |
|---|---|
| Part Number | CAB-8644/QSFP-P2M(1pc) |
| Frequency | 10000000000.000000 |
| Voltage Unit | Volts |
| Data Transfer Rate | 10.000000 |
| Gauge Decimal Value | 30.000000 |
| Cable Length Decimal Value | 6.560000 |
| Cable Length String Value | 6.56 feet |
| Cable Length Unit | Feet |
