NeNchengLi RSC-2050 Hydraulic Cylinder Jack and Hydraulic Hand Pump CP-180, 20T Hydraulic Jack Porta Power Kit 2In Stroke, Industrial Mini Hydraulic Lifting Cylinder
- Hydraulic Jacks Specs--Shape: Cylinder, Material: Steel, Interface Size: 3/8'', Maximum Output Pressure:700/10000KG/CM2, Total Tonnage: 20T/44092lbs, Stroke: 50mm/2in, Travel: 50min.
- Strong Lifting Force--The hydraulic cylinder jack boasts a substantial lifting capacity of 4,4092 lbs, which enables it to lift heavy objects of significant weight with ease. The impressive lifting force renders it a versatile and efficient option for fulfilling various lifting requirements.
- Thoughtful Design--20T hydraulic jacks can be used in narrower and lower spaces and has a stroke of 2 inches to meet your usage needs. In addition, the large oil storage capacity makes it can be used for a long time, avoiding frequent additions.
- Simple Operation--You can tighten the return switch on the hydraulic pump clockwise, press the handle and hydraulic jack automatically jacks up. After loosening the return switch, the jack automatically retracts. The direction of the use of the jack is not restricted and can be used horizontally, or upside down.
- Clear Gauge--It makes it easier for you to observe changes in pressure and make timely adjustments. This porta power kit is made of high-class steel with a plastic spraying treatment, making it impact-resistant and not easy to deform.
- Application--Hydraulic cylinder jack and hand pump can be used for the installation and maintenance of large and medium-sized mechanical equipment in construction sites, petroleum, electric power, ships, bridges, steel, and other industries. It can be used with punching machines, cutting machines, bending machines, cable cutter hydraulic pliers, and other machines.
Description
This hydraulic jack+hand pump allows you to lift heavy objects with ease. Its excellent performance is complemented by convenient operation, which not only greatly improves work efficiency, but also demonstrates the charm of the ideal combination of mechanical aesthetics and practical functions. It is an indispensable and ideal assistant in factories, construction sites, warehouses, docks, railroad or ship construction, and other places.
Specification
Cylinder Model: RSC-2050
Hand Pump Model: CP-180
Color: Green
Shape: Cylinder
Material: Steel
Process: Plastic Spraying
Interface Size: 3/8''
Maximum Output Pressure:700/10000KG/CM2
Output Pressure: High Pressure 60KG/CM2
Length of Oil Pipe: 1m/3.28ft
Total Tonnage: 20T/44092lbs
Stroke: 50mm/2in
Travel: 50min
Collapsed Height: 105mm/4.13in
Extended Height: 155mm/6.1in
Cylinder Jack Size(D*H): 9*10.6cm/3.54*4.17inch
Hand Pump Size: 34*10*14cm/13.39*3.94*5.51inch
Package Size: 37.5*22.5*16.5cm/14.76*8.86*6.5inch
Gross Weight: 7kg/15.43lbs
Net Weight: 6kg/13.23lbs
Package Included
1* Hydraulic Cylinder Jack
1* Hand Pump
Notes
1. Please use the product on a flat surface, not on soft or rough ground, and do not apply unilateral force to the spindle.
2. If there is a slight oil leak at the interface, you can wrap it with a raw material belt (not included).
3. There is hydraulic oil in the hydraulic pump. After a long time of use, you need to refuel yourself, it is recommended to use No.15 hydraulic oil (not included).
4. Before use, the interface between the jack and the pump should be installed firmly, otherwise it will leak oil. A slight oil leak at the interface is normal.
5. The first time you use it, you need to press the hydraulic pump a few more times to remove the air inside the jack.
| Brand Name | NeNchengLi |
|---|---|
| Part Number | QL-HCJP1 |
| Load Capacity | 20 |
