12 Steps Retractable Loft Access Ladder, 27.56in Wide Attic Ladder Pull Down System, Wall Mounted Telescoping Staircase for 9.51-10.17ft Wall Height, Up to 661lbs, Black, White
- 【High Quality Material】: The telescopic ladder is mainly made of high-quality cold rolled steel with high strength and hardness, which is sturdy and durable. The door plate is made of wood and paint-free fireproof board, outsourced with PVC cladding, which greatly improves the service life of the door plate
- 【High Adaptability】: This wall-mounted Folding Ladder is suitable for ceiling thicknesses from 5.12-9.84 inches, making it easier to install on a variety of ceiling structures. The vertical applicable height is less than 11.48 feet to meet your usage needs. Suitable for attics, lofts, basements, warehouses, stores, etc
- 【Strong Load Capacity】: High strength cold rolled steel plate, strong rivets fixing, scientific s-shape design, sturdy structure, make this loft ladder support up to 661.39 pounds, which can withstand daily high-intensity use and is a good helper for going up and down the attic
- 【Foldable Design】: You can use the pull bar to help you pull down this staircase, easy to use, push it up and fold it to save space. Sturdy springs ensure smooth and labor-saving expansion without making noise
- 【Safe and Reliable】: PVC base and non-slip rubber feet ensure high stability without sliding and scratching the floor. Wide and thick steps (15.75*5.51 inches) with non-slip pattern provide stable support for you to go up and down the stairs
How to Install
1. Drill a hole from the bottom and insert the lock cylinder into the fixed part.
2. Attach the lock.
3. Tighten the fixing screws.
4. Use a rope to lift the stairs to the mounting holes in the ceiling.
5. Place the triangular steel plate on the staircase and tighten the fixing screws.
6. Installation is complete.
Specification
Number of Steps: 12
Type: Ceiling Mount
Load-bearing Capacity: 300kg/661.39 lbs
Installation Vertical Height: Less Than 3.5m/11.48 ft
Total Ladder Width: 44cm/17.32in
Step Size: 40*14cm/15.75*5.51in
Height Between Steps: 24-25cm/9.44- 9.84in
Applicable Opening: 100*70cm/39.37*27.56 in
Distance Between Opening Edge and Walls: More Than 5cm/1.97in
Required Opening Bottom Operating Space: More Than 1.6m/5.25ft
Ceiling Thickness: 13-25cm/5.12-9.84in
Package Size: 110*80*48cm/43.3*31.5*18.9in
Gross Weight: 61kg/134.48 lbs
Net Weight: 58kg/127.86 lbs
Notes
1. Please check the style and size before purchasing.
2. It only fits for ceiling installation, not suitable for vertical walls. It is recommended that a vertical height of less than 11.48 ft is fine.
3. It is recommended that the screws be inspected regularly and tightened as needed to ensure continued safety and longevity.
4. The recommended ceiling thickness is 5.12-9.84in because a thin ceiling is easy to card and is not tight. The ceiling material is suggested to be channel steel, thick square tube, cast-in-place board, thick wooden board, and other bearing structures.
| Brand Name | Fifizoo |
|---|---|
| Part Number | E5-007 |
| Load Capacity | 661.39 |
| Item Height Unit | Inches |
| Height Top to Bottom | 39.370000 |
| Item Width Unit | Inches |
| Item Width Side to Side | 27.560000 |
| Number of Steps | 12 |
| Maximum Height Unit | Feet |
| Maximum Height | 10.170000 |
