30T Hydraulic Cylinder Jack Sets, Low Profile Hydraulic Jack Porta Power Kit with CP-700 Hydraulic Hand Pump Hydraulic Ram Cylinder Jack Single-Acting Industrial Mini Jack Ram
- 【Good Materials:】 This product is made of high-quality steel and rubber, which is strong, durable, and not easy to deform. Good materials can extend its service life.
- 【Large Tonnage: 】It has a tonnage of 30T/66138lbs, which is suitable for shipyards, bridges, large machines.
- 【Easy to Operate: 】You just need to press the handle up and down to jack up heavier items, so it is very labor-saving and convenient to use.
- 【Quick Coupling: 】The quick coupling adopts threaded ZG3/8, which is equipped with a steel ball to prevent oil leakage, making it safer to use.
- 【Easy to Install: 】This product is simple in structure and fully packaged. You need to connect the jack and pump to use, which is very simple and can save a lot of time and effort.
Description
This hydraulic jack is made of high-quality steel and rubber, which is strong, durable, and not easy to deform. It has a tonnage of 30T/66138lbs, which is large enough to meet your work needs. You can press the pump handle to jack up heavier items easily, so it is very labor-saving and convenient to use.
Application
It is often used in power, chemical, steel, bridges, and other industries. It is suitable for railway vehicle maintenance, mechanical installation, construction engineering support, etc.
Specification
Color: Black, Yellow, Silver
Material: Steel
Quick Coupling Type (Thread): ZG3/8
Fuel Hose Material: Rubber
Gross Weight: 16.5kg/36.3lbs
Package Size: 64*19*18.5cm/25.1*7.4*7.2inch
Jack Model: RSC-3050
Tonnage: 30T/66138lbs
Travel(Adjustable Height): 50mm/1.9inch
Jack Height: 105mm/4.1inch
Jack Extended Height: 155mm/6.1inch
Jack Diameter: 104mm/4.09inch
Oil Storage Capacity: 210CC
Jack Weight: 5.5kg/12.1lbs
Pump Model: CP-700
Oil Storage Capacity: 700CC
Pump Max. Pressure: 70MPa
Pump Min. Pressure: 7MPa
Pump Weight: 10.5kg/23.1lbs
How to Use
1.First, connect the quick connector of the manual pump to the jack.
2.Select the position and tighten the hydraulic pump drain screw clockwise.
3.Press the handle up and down.
4.When you can see the coil on the spindle, stop pressing.
5.Loosen the hydraulic pump oil drain screw counterclockwise.
Package Included
1* Hydraulic Jack
1* Pump
| Brand Name | InnaMall |
|---|---|
| Part Number | BI-217-QXF |
