MECCANIXITY 1000A Brass G-Shape Ground Welding Earth Clamp C-Clamp T-Handle Maximum Clamping Range 73mm Rod Holder for Welding Machine
$47.44
- This is a welding machine grounding clamp used to provide a more stable welding environment. Brass ground clamps eliminate or reduce static electricity and electromagnetic interference that may occur during welding. They are widely applied for ship-yards, steel structures, oil platforms, motor car manufacturing, curtain wall industry, auto parts and other.
- Rated current: 1000A; Dimensions: 168 x 25 x 103 mm/6.61 x 0.98 x 4.06 inch; Clamping range: 0-73mm/2.87 inch; Total screw length: 31mm/1.22 inch; Thread length: 25mm/0.98 inch; Thread specification: M10*1.5mm/0.06 inch; Inner diameter: 10mm/0.39 inch; Color: Brass; Material: Brass; Rated voltage range: AC single-phase and DC 50V and below; In the package of: 1 x welding machine grounding clamp with 1 x Gasket and 1 x Washer
- The welder ground clamp is made of brass material that offers good conductivity, oxidation resistance and long service life.The performance of the welded grounding clamp is stable, which has high reliability, can be are placement part for manual welder.
- 1.Attach the ground clamp to the weldable part of the welding workpiece; 2.After confirming that the grounding clamp is safely and securely connected, turn on the welder and perform the desired welding operation.
- Please ensure that avoid touching workpieces that are not properly grounded during the welding process to prevent the risk of electric shock; avoid touching the exposed electrodes and other high-temperature parts of the welding machine.
This product is fulfilled by seller
What is this?
This is a welding machine grounding clamp used to provide a more stable welding environment. Brass ground clamps eliminate or reduce static electricity and electromagnetic interference that may occur during welding. They are widely applied for ship-yards, steel structures, oil platforms, motor car manufacturing, curtain wall industry, auto parts and other.
What will I get?
Rated current: 1000A
Dimensions: 168 x 25 x 103 mm/6.61 x 0.98 x 4.06 inch
Clamping range: 0-73mm/2.87 inch
Total screw length: 31mm/1.22 inch
Thread length: 25mm/0.98 inch
Thread specification: M10*1.5mm/0.06 inch
Inner diameter: 10mm/0.39 inch
Color: Brass
Material: Brass
Rated voltage range: AC single-phase and DC 50V and below
In the package of: 1 x welding machine grounding clamp with 1 x Gasket and 1 x Washer
Are there any advantages of the product?
The welder ground clamp is made of brass material that offers good conductivity, oxidation resistance and long service life.The performance of the welded grounding clamp is stable, which has high reliability, can be are placement part for manual welder.
How to use it?
1.Attach the ground clamp to the weldable part of the welding workpiece; 2.After confirming that the grounding clamp is safely and securely connected, turn on the welder and perform the desired welding operation.
What should I notice?
Please ensure that avoid touching workpieces that are not properly grounded during the welding process to prevent the risk of electric shock; avoid touching the exposed electrodes and other high-temperature parts of the welding machine.
This is a welding machine grounding clamp used to provide a more stable welding environment. Brass ground clamps eliminate or reduce static electricity and electromagnetic interference that may occur during welding. They are widely applied for ship-yards, steel structures, oil platforms, motor car manufacturing, curtain wall industry, auto parts and other.
What will I get?
Rated current: 1000A
Dimensions: 168 x 25 x 103 mm/6.61 x 0.98 x 4.06 inch
Clamping range: 0-73mm/2.87 inch
Total screw length: 31mm/1.22 inch
Thread length: 25mm/0.98 inch
Thread specification: M10*1.5mm/0.06 inch
Inner diameter: 10mm/0.39 inch
Color: Brass
Material: Brass
Rated voltage range: AC single-phase and DC 50V and below
In the package of: 1 x welding machine grounding clamp with 1 x Gasket and 1 x Washer
Are there any advantages of the product?
The welder ground clamp is made of brass material that offers good conductivity, oxidation resistance and long service life.The performance of the welded grounding clamp is stable, which has high reliability, can be are placement part for manual welder.
How to use it?
1.Attach the ground clamp to the weldable part of the welding workpiece; 2.After confirming that the grounding clamp is safely and securely connected, turn on the welder and perform the desired welding operation.
What should I notice?
Please ensure that avoid touching workpieces that are not properly grounded during the welding process to prevent the risk of electric shock; avoid touching the exposed electrodes and other high-temperature parts of the welding machine.
| Brand Name | MECCANIXITY |
|---|---|
| Part Number | mea231108ee000153 |
| California Proposition 65 Warning Type | Chemical |
