Hydraulic Jack 30T/66138lbs, Mini Protable Hydraulic Cylinder Industrial Lifting Jack with CP-700 Pump, Single Acting Lifting Cylinders for Railway Vehicle Maintenance, Mechanical Installation
- Quick Coupling: The quick coupling adopts threaded ZG3/8, which is equipped with a steel ball to prevent oil leakage, making it safer to use.
- Easy to Operate: You just need to press the handle up and down to jack up heavier items, so it is very labor-saving and convenient to use.
- Large Tonnage: It has a tonnage of 30T/66138lbs, which is suitable for shipyards, bridges, large machines.
- Easy to Carry: The product is a split type, you can detach the jack and pump to convenience you to carry.
- Easy to Install: This product is simple in structure and fully packaged. You need to connect the jack and pump to use, which is very simple and can save a lot of time and effort.
Description
This hydraulic jack is made of superior steel and rubber, which is strong, durable, and not easy to deform. It has a tonnage of 30T/66138lbs, which is large enough to meet your work needs. You can press the pump handle to jack up heavier items easily, so it is very labor-saving and convenient to use.
Details
Stop Ring: The stop ring can play a protective role for the jack to prevent breakage and damage when it is under load, making it safer to use.
Plastic Spraying Treatment: The housing of the jack is treated with plastic spraying, so it is not easy to lose paint and rust, which can prolong the service life of this product.
Anti-slip Circles: There are raised anti-slip circles above the spindle that can play an anti-slip effect to ensure that the objects placed on it will not slide casually. This makes it safer for you to use.
Anti-slip Handle: The handle is designed with an anti-slip pattern, which can play a good anti-slip effect and enhance safety in use.
Application
It is often used in power, chemical, steel, bridges, and other industries. It is suitable for railway vehicle maintenance, mechanical installation, construction engineering support, etc.
Specification
Color: Black, Yellow, Silver
Material: Steel
Quick Coupling Type (Thread): ZG3/8
Fuel Hose Material: Rubber
Gross Weight: 16.5kg/36.3lbs
Package Size: 64*19*18.5cm/25.1*7.4*7.2inch
Jack Model: RSC-3050
Tonnage: 30T/66138lbs
Travel(Adjustable Height): 50mm/1.9inch
Jack Height: 105mm/4.1inch
Jack Extended Height: 155mm/6.1inch
Jack Diameter: 104mm/4.09inch
Oil Storage Capacity: 210CC
Jack Weight: 5.5kg/12.1lbs
Pump Model: CP-700
Oil Storage Capacity: 700CC
Pump Max. Pressure: 70MPa
Pump Min. Pressure: 7MPa
Pump Weight: 10.5kg/23.1lbs
How to Use
1. First, connect the quick connector of the manual pump to the jack.
2. Select the position and tighten the hydraulic pump drain screw clockwise.
3. Press the handle up and down.
4. When you can see the coil on the spindle, stop pressing.
5. Loosen the hydraulic pump oil drain screw counterclockwise.
Package Included
1* Hydraulic Jack
1* Pump
Notes
1. Please keep the load bearing surface hard and flat and do not exceed the tonnage and rated strok, otherwise, the cylinder will be damaged.
2. It is only applicable to railroad vehicle maintenance, machinery installation, construction project support, etc., not applicable to household cars.
3. The package does not include hydraulic oil, please buy it locally by yourself. Thank you for your understanding.
4. Please stop immediately when you see the stop line.
5. Please allow the slight color difference caused by the shooting light and 1-3cm error due to manual measurement, and make sure you do not mind before ordering.
| Brand Name | ACNAO |
|---|---|
| Part Number | Hydraulic Jack 30T/66138lbs |
| Load Capacity | 30 |
