Fuel Sending Unit Boat Car 52mm Gauge Sewage Level Gauge with Alarm Fit 0-190ohm/240-33ohm Holding Tank Sewage Level Sender Sensor(150mm-240ohm)

Boat Car 52mm Gauge Sewage Level Gauge with Alarm Fit 0-190ohm/240-33ohm Holding Tank Sewage Level Sender Sensor

Specifications:
- Material: stainless steel 316.
- Easy dismounting and convenient for cleaning.
- Waterproof, Stainless Steel 316,Work in Vile Condition.
- This series are mainly used in holding tank, special design can make it work in vile condition for long term.
- Applying the principle of magnetic field to control the reed on-off switch, featuring long using life, anti-vibration, anti-explosion, etc

Feature:
- Protection Rank: IP67
- Length: 150mm ~ 600mm
- Resolution Range: 10-40mm
- Material: 316 Stainless Steel
- Operational temperature: -40°C ~ +85°C
- Application: for marine boat car truck RV
- Output signal: 0~190 ohm (Standard European),
240~33 ohm (Standard American)

Package Include:(as picture):
1 x Sewage Sensor

Sewage Level Gauge

Specification :
-Installation Diam:52mm
-Item Name: Holding Tank Level Gauge
-Materials:stainless steel+plated plastic
-Operating Voltage: 12V/24V
-Indicating Range: Low-Full
-Input signal: 0-190ohm or 240~33 ohm
-Protection Class: IP67,can work underwater 1m position
-Alarm Model : Red Indicator Light Flashes (HTG>75%)

Connectioning:
Black:Ground(-)
Red:9-30VDC
Blue:Signal Input
Yellow:Backlight

Package Includes:
1 x Holding Tank Level Gauge
1 x Cable
1 x Owner's Manual
